Fortinet FSM-3500G server 96 TB Rack (4U) Intel® Xeon® Gold 5118 2.3 GHz 128 GB DDR3-SDRAM

Fortinet

FSM-3500G

Server 96 TB Rack (4U) × Intel® Xeon® Gold 5118, 128 GB DDR4-SDRAM

The Fortinet FSM-3500G is an all-in-one, rack-mountable security and event correlation appliance tailored for mid-to-large sized enterprises, MSSPs, and data centers. Equipped with dual Intel® Xeon® Gold 5118 processors (12 cores / 24 threads each) clocked at 2.3 GHz, a generous 128 GB DDR4-ECC RAM, and a massive 96 TB SAS storage array, this 4U powerhouse delivers high-throughput log collection, real-time analytics, and unified security monitoring. Ideal for security operations centers (SOCs) running FortiSIEM, it can handle up to 40 K events per second (EPS) when paired with Fortinet collectors, providing deep visibility into both IT and security events.

Features

The Fortinet FSM-3500G is designed as a robust, all-in-one FortiSIEM supervisor-and-worker server. At its core, the unit features dual Xeon Gold 5118 CPUs, offering 24 physical cores and 48 logical threads in total×ensuring efficient multi-threaded processing for real-time correlation, asset discovery, UEBA, and threat managementBacked by 128 GB DDR4 ECC memory and a 96 TB hot-swappable SAS drive configuration (24×4 TB), it offers both capacity and resilience for sustained log retention and fast storage access .

Advanced Options

Network flexibility is achieved via built-in interfaces×2× 1 GbE RJ-45, 2×1 GbE SFP, and 2×25 GbE SFP28×along with four expansion slots for additional SFP/SFP28 ports . Ideal for deployments requiring segregation of management, logging, and event traffic, it ensures high-bandwidth ingestion without bottlenecks. The appliance handles up to 40 K EPS with collectors, ensuring scalable analytics and rapid threat detection

Product Key Features

• Dual Intel® Xeon® Gold 5118 processors (12C/24T @ 2.3 GHz each)

• 128 GB DDR4 ECC RAM for high-scale analytics

• 96 TB hot-swappable SAS storage (24×4 TB drives)

• 40 K EPS (with collectors) for high-volume environments

• Flexible I/O: 2×1 GbE RJ-45, 2×1 GbE SFP, 2×25 GbE SFP28, plus expansion

• 6× USB 3.0 ports, console DB9 port

---

Reliability & Performance

he FSM-3500G is engineered for enterprise-class performance in a 4U chassis. Dual Xeon Gold 5118 CPUs (24 cores total, 48 threads) provide robust processing to support concurrent analytics workloads, including real-time correlation, UEBA, and asset discovery . The 128 GB of DDR4 ECC memory supports large data buffers and query workloads across complex environments. Its storage subsystem comprises 24 x 4 TB SAS drives configured in a hot-swappable array, delivering 96 TB raw capacity (~75 TB usable database storage) for long-term log retention and fast search capabilities. High network throughput is enabled by 25 GbE SFP28 ports and additional GbE interfaces, ensuring that large-scale deployments can ingest and process streams without interruption

Key Features (Bullet List)

• Dual Xeon Gold 5118 CPUs (12C/24T x2)

• 128 GB DDR4 ECC memory

• 96 TB hot-swap SAS drives (24×4 TB)

• Up to 40 K EPS with collectors

• 2×1 GbE RJ-45, 2×1 GbE SFP, 2×25 GbE SFP28

• 6× USB 3.0, console port DB9

• Redundant AC power supplies

• 4U rack-mount chassis

Specifications :

Product Specifications

Specification	Details
Model Number	FSM-3500G
Type	Rack-mount Security / SIEM Appliance
CPU	2× Intel® Xeon® Gold 5118 (12C/24T, 2.3 GHz, 16.5 MB L3 cache, up to 3.2 GHz Turbo)
Memory	128 GB DDR4 ECC (16GB ×8)
Storage Capacity	96 TB SAS (24×4 TB hot-swappable) × ~75 TB usable
Max Events/sec	40,000 EPS (with collectors)
Network Ports	2× 1 GbE RJ-45, 2× 1 GbE SFP, 2×25 GbE SFP28, 4 expansion slots (SFP/SFP28)
USB Ports	6× USB 3.0
Console Port	DB-9 serial
Power Supply	Dual AC (100-240 V, 50/60 Hz)
Power Consumption	Avg. 645 W, Max 696 W
Form Factor	4U rack-mount (17.2″ W × 26″ D × 7″ H / 437×660×178 mm)
Weight	~90.75 lb (41.2 kg)
Certifications	FCC Part 15A, CE, UL/cUL, VCCI, RCM
