Overview FC830
The Dell PowerEdge FC830 server block is a powerhouse featuring dense computing, memory, and storage. It's designed for medium to large-scale businesses running mission-critical applications, databases, or high-performance computing. It's also an excellent choice for large-scale virtualization.
Performance FC830
This system features Intel's C610 chipset, which can support either the Xeon E5-4600 v3 processors with up to 18 cores each or the E5-4600 v4 processors with up to 22 cores each. With two of these server sleds installed in the PowerEdge FX2 chassis, it will support an impressive eight processors and 176 cores total in a 2u space.
Memory FC830
The system board supports 48 DIMM sockets, with each processor of the four CPUs assigned 12 DIMM slots. Paired with an appropriate v4 processor, DDR4 LRDIMM memory modules offer transfer speeds of up to 2400MT/s. With a full complement of quad-rank 64GB LRDIMM modules installed on the system, that adds up to an impressive 1.5TB of memory. Cut that in half if you plan on using RDIMM modules, which are only supported with dual-rank 32GB modules.
Storage FC830
Administrators can choose from either an 8-bay chassis supporting up to eight 2.5-inch drives, or a 16-bay version supporting up to 16 1.8-inch SSDs. SAS and SATA HDD/SSDs are supported including optional PowerEdge Express Flash NVMe PCIe drives. There are several PERC RAID controllers supported on the system offering the full range of RAID options.
Specifications FC830:
Base: PowerEdge FC830
Dimensions:
W: 48.8 cm (19.2 in)
D: 37.6 cm (14.8in)
H: 5.1 cm (2 in)
Form Factor:
Full-width – supports up to 2 sleds per PowerEdge FX2 enclosure
Processor:
Intel® Xeon® processor E5-4600 v4 product family
Processor sockets: 4
Cache: 2.5MB per core; core options: 4, 6, 8, 10, 12, 16, 18, 22
Chipset:
Intel C610 series power Supplies:
Chassis level – PowerEdge FX2 hot-plug PSU: 2000W or 1600W AC in 1+1 redundant or 2+0 non-redundant configurations
Memory:
Up to 1.5TB (48 DIMM slots): 4GB/8GB/16GB/32GB/64GB DDR4 up to 2400MT/sI/O Mezzanine Cards:
Access to 4 x PCIe 3.0 (x8) expansion slots, (up to 8 for certain configurations)Internal Controllers:
PERC S130 (SW RAID), PERC H330, PERC H730, PERC H730P
Primary Storage:
Hot-plug hard drive options:
PowerEdge Express Flash NVMe PCIe, SATA HDD/SSD or SAS HDD/SSD
Up to 16 x 1.8" SSD or 8 x 2.5"
Optional Adapters:
Optional NICs and HBAs
Video Card:
Video type: Matrox® G200 (integrated with iDRAC8)
Video memory: 16MB shared with iDRAC8 application memory
Systems Management:
FX uses a Chassis Management Controller (CMC) to manage all resources (server nodes and shared infrastructure) in a single web console
OpenManage portfolio for FX supports local and remote management, consistent with other PowerEdge products
CMC and iDRAC are available with either Enterprise or Express licensing to best suit specific management needs
Server nodes each contain proven iDRAC8 with Lifecycle Controller for agent-free, automated systems
managementOperating Systems:
Microsoft® Windows Server® 2008 R2
Microsoft Windows Server 2012
Microsoft Windows Server 2012 R2
Novell® SUSE® Linux Enterprise Server
Red Hat® Enterprise Linux
VMware
