Dell EMC PowerEdge R740xd2 Rack Server – High-Capacity Storage

New

Dell

×




  • New

Detailed Specifications

Dell EMC PowerEdge

R740xd2

Rack Server – High-Capacity Storage

The Dell EMC PowerEdge R740xd2 is a purpose-built rack server engineered to provide massive storage scalability and reliable performance. Ideal for backup, archival, video surveillance, and content delivery workloads, the R740xd2 balances compute and capacity in a dense 2U form factor

Features

Designed for data-heavy workloads, the PowerEdge R740xd2 offers up to 26 front-accessible 3.5" drives, providing high-density storage in a compact footprint. This server is perfect for businesses that need to retain and process large datasets without sacrificing performance or floor space. The R740xd2 also features support for GPU accelerators and PCIe expansion, allowing for future-ready flexibility

Advanced Options

With dual Intel Xeon Scalable processors and scalable memory architecture, the R740xd2 supports modern virtualization and SDS (Software-Defined Storage) solutions. Its comprehensive remote management capabilities and high-availability features make it a reliable cornerstone for any enterprise IT strategy.

Product Key Features

  •  Supports up to 2x Intel Xeon Scalable processors for powerful performance

  •  Houses up to 26x 3.5” drives – ideal for high-capacity storage environments

  •  Dual redundant hot-plug power supplies ensure continuous uptime

  •  Flexible I/O with support for 2x 10GbE and multiple PCIe Gen3 slots

  •  Integrated iDRAC9 with Lifecycle Controller for secure remote management

  •  Optimized thermal design for reliable performance in high-density deployments

Reliability & Performance

The R740xd2 includes hot-swappable drive bays, redundant power supplies, and intelligent system cooling to ensure 24/7 uptime. Integrated iDRAC9 with Lifecycle Controller gives IT admins full remote control over system health, updates, and deployment. Engineered with Dell’s comprehensive cybersecurity framework, it provides secure boot, TPM 2.0, and System Lockdown to protect mission-critical data.

Key Features (Bullet List)

  • Supports 2x Intel Xeon Scalable processors (up to 28 cores each)

  • Up to 1TB DDR4 RAM with 16 DIMM slots

  • Up to 26x 3.5" front drives + 2x 2.5" rear optional drives

  • Redundant hot-plug 1100W or 1600W power supplies

  • iDRAC9 with Lifecycle Controller for remote management

  • Supports RAID via PERC H740P or HBA330 controllers

  • 2U rackmount chassis with tool-less access

  • Optional support for GPUs or caching SSDs

  • Secure Boot, TPM 2.0, and system lockdown for enhanced protection

  • Ideal for SDS, file serving, backup & archival use cases

Specifications :

SpecificationDetails
Model Number PowerEdge R740xd2
Server Type Rackmount – 2U
Processor Support Dual Intel Xeon Scalable (1st or 2nd Gen)
Memory Capacity Up to 1TB DDR4 ECC RDIMM
Drive Bays Up to 26x 3.5” SAS/SATA (front), 2x 2.5” rear optional
RAID Controller PERC H740P or HBA330
Networking Dual 1GbE/10GbE ports via add-on cards
Expansion Slots Up to 5x PCIe Gen3
Power Supply Redundant 1100W or 1600W Platinum
Management iDRAC9 with Lifecycle Controller
Dimensions 3.4" H x 17.5" W x 31.25" D (2U)
Weight Approx. 68–85 lbs (varies with config)
