Dell PowerEdge R740xd 24 Bay SFF 2U Server

New

PowerEdge R740xd Rack Server Optimized scalability and performance
×




  • New

Detailed Specifications

Dell PowerEdge

R740xd

2U Rack Server – Intel Xeon Bronze 3204, 8GB DDR4, 600GB 10K SAS, H330 RAID, 12-Bay 3.5", 750W PSU

The Dell PowerEdge R740xd is a flexible and storage-dense 2U rack server built for performance scalability and versatility. Ideal for entry-level virtualization, storage arrays, or business-critical applications, this refurbished model features an Intel Xeon Bronze 3204 processor, 600GB 10K SAS drive, and Dell’s trusted H330 RAID controller — all within a 12-bay chassis to meet growing data needs.

Features

Built for demanding workloads, the R740xd provides a powerful platform that balances performance and storage flexibility. This configuration includes 1x Xeon Bronze 3204 CPU, 8GB of DDR4 ECC RAM, and a 600GB 10K SAS drive, making it suitable for smaller enterprise environments that require consistent uptime and scalability.

Advanced Options

With up to 12x 3.5" drive bays, the server supports massive local storage expansion — perfect for backup servers, file repositories, or data-intensive applications. The built-in H330 RAID controller adds a layer of redundancy and performance optimization.

Product Key Features

  •  Intel Xeon Bronze 3204 – 6 cores for entry-level enterprise computing

  •  8GB DDR4 ECC Registered RAM – Expandable and reliable performance

  •  600GB 10K SAS Drive – High-speed enterprise storage

  •  Dell H330 RAID Controller – Ensures data redundancy and protection

  •  750W Power Supply – Energy-efficient and enterprise-grade

  •  12x 3.5” Drive Bays – Scalable storage capacity

Reliability & Performance

Designed for high availability and consistent operation, the R740xd supports redundant PSU options, hot-swappable drives, and remote system management through iDRAC9 (license optional). The 750W power supply ensures power efficiency while maintaining performance headroom for additional components or future upgrades.

Key Features (Bullet List)

  • 1x Intel Xeon Bronze 3204 (6-core, 1.9GHz)

  • 1x 8GB DDR4 ECC RDIMM (Expandable up to 3TB)

  • 1x 600GB 10K SAS 3.5” Enterprise Drive

  • Dell PERC H330 RAID Controller

  • 12x 3.5” Hot-Swap Drive Bays

  • 1x 750W Power Supply Unit

  • No Optical Drive

  • 2U Rackmount Chassis

  • iDRAC9 Management Port (Enterprise license optional)

  • Ideal for storage-focused deployments and virtualizati

Specifications :

SpecificationDetails
Model Number Dell PowerEdge R740xd
Server Type 2U Rackmount
Processor 1x Intel Xeon Bronze 3204 (6 cores, 1.9GHz)
Memory Installed 1x 8GB DDR4 ECC RDIMM
Max Memory Up to 3TB DDR4 (24 DIMM slots)
Storage 1x 600GB 10K RPM SAS Hard Drive
Drive Bays 12x 3.5” Hot-Swap Bays
RAID Controller Dell PERC H330
Optical Drive None
Power Supply 1x 750W Platinum PSU
Remote Management iDRAC9 (license optional)
Dimensions (HxWxD) 3.4" x 17.5" x 28.7" (8.7cm x 44.5cm x 73cm)
Weight Approx. 65 lbs (29.5 kg)
