Detailed Specifications
Dell EMC PowerEdge R7515
Let us know what is Your needs, We can design as per your required specifications, Get in touch with sales@dcsupplies.net
Overview R7515
The Dell EMC PowerEdge R7515 rack server is a highly scalable single-socket 2U rack server that delivers outstanding performance and TCO. Built on scalable system architecture. Designed to flexibly meet software-defined storage, virtualization, and data analytics performance needs.
Deliver breakthrough performance, innovation, and density for traditional and emerging workloads
Data center evolution starts with modern platforms that scale easily and are optimized for application performance. The PowerEdge R7515 is built upon a scalable system architecture and provides choice and flexibility to meet performance demands. High-level specifications:
- 100%1 more processing cores and faster data transfer speeds with PCIe Gen 4
- 20%2 more memory performance for scale-out environments
- Direct connect SAS/SATA/ NVMe for vSAN Ready Nodes
- High core count performance for the highest VM density in a single-socket design
- Multi-die architecture offers low latency and floating-point performance for Big Data and Containers
Increase efficiency and accelerate operations with an automated infrastructure
The Dell EMC OpenManage systems management portfolio delivers an efficient and comprehensive solution for PowerEdge servers through tailored, automated, and repeatable processes.
- Automate server life cycle management with scripting via the iDRAC Restful API with Redfish conformance.
- Simplify and centralize one-to-many management with the OpenManage Enterprise console.
- Utilize the OpenManage Mobile app and PowerEdge Quick Sync 2 to easily manage servers using a phone or tablet.
- Resolve issues with up to 72% less IT effort using automated proactive and predictive technology from ProSupport Plus and SupportAssist.
Specifications R7515:
Hard Drive Capacity
480 GB
Number of Processors
Single Processor
General
Bundled Services
3 Years Basic Hardware Warranty Repair, 5x10 HW-Only, 5x10 NBD On-site - Disti SNS
Product Form Factor
Rack-mountable - 2U
Cache Memory
Installed Size
L3 cache - 128 MB
Cache Per Processor
128 MB
RAM
Installed Size
16 GB / 1 TB (max)
Effective Memory Speed
3200 MHz
Rated Memory Speed
3200 MHz
Features
Registered, dual rank
RAM Supported
1 TB registered 2 TB 3DS Load-Reduced
Hard Drive
Type
SSD - hot-swap - 2.5"
Interface Type
SATA 6Gb/s
Features
1 DWPD, Read Intensive
Storage Controller
Storage Controller Name
Dell PERC H730P
Graphics Controller
Graphics Processor
Matrox G200eR2
Networking
Interface (Bus) Type
LAN-on-motherboard (LOM)
Ethernet Ports
2 x Gigabit Ethernet
Ethernet Controller
Broadcom BCM5720
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller
Integrated Dell Remote Access Controller 9 X5 Enterprise (iDRAC9 X5)
Expansion / Connectivity
Bays
8 (total) / 7 (free) x hot-swap 3.5"
Slots
2 PCIe x16 - full-height 2 PCIe x16 - low-profile
Interfaces
2 x USB 3.0 - Type-A 2 x USB 2.0 - Type A (2 in front) 1 x management - micro-USB (1 in front) (iDRAC Direct port) 1 x serial 2 x VGA (1 front, 1 rear) 2 x LAN (Gigabit Ethernet) 1 x management (iDRAC dedicated port)
Miscellaneous
Included Accessories
Riser card, ReadyRails static rails for 2/4-post racks
Pricing Type
Build To Plan (BTP)
Power
Device Type
Power supply - hot-plug
Power Redundancy
Optional
Power Redundancy Scheme
1+1 (with optional power supply)
Voltage Required
AC 230 V (50/60 Hz)
80 PLUS Certification
80 PLUS Titanium
Operating System / Software
OS Provided
No operating system
