Detailed Specifications
HPE P83285-005 ProLiant DL360 Gen11 Server
Overview
The HPE P83285-005 is a ProLiant DL360 Gen11 1U rack server optimized for dense compute deployments. It is powered by a 12-core Intel Xeon Silver 4510 CPU and comes preinstalled with 64 GB of DDR5 Registered Smart Memory. The system supports four large-form-factor (LFF) 3.5″ drive bays for high-capacity storage needs. It includes dual 800 W Flex-Slot power supplies for redundancy and an OCP 3.0 network adapter, and is managed via HPE iLO 6 for remote operation and monitoring.
Key Features
12-core Intel Xeon Silver 4510 at 2.40 GHz
64 GB DDR5 Registered Smart Memory installed
4 × 3.5″ LFF hot-plug SATA drive bays (2 × 4 TB HDDs preinstalled)
Embedded Broadcom 4-port 1 Gb BASE-T OCP3 adapter
Dual 800 W Flex-Slot redundant power supplies
HPE iLO 6 for remote server management
Compact 1U chassis with enterprise-class reliability
Technical Specifications
| Specification | Details |
|---|
| Brand | HPE |
| Part Number | P83285-005 |
| Product Type | 1U Rack Server |
| Processor | Intel Xeon Silver 4510, 12 cores, 2.40 GHz |
| L3 Cache | 30 MB |
| Memory (Installed) | 64 GB (2 × 32 GB) DDR5 Registered |
| Maximum Memory Supported | Up to 8 TB DDR5 |
| Memory Slots | 32 DIMM slots |
| Drive Bays | 4 × 3.5″ LFF hot-plug |
| Included Storage | 2 × 4 TB SATA HDD |
| Storage Controller | Embedded SATA / SAS / NVMe support |
| Network Adapter | Broadcom BCM5719, 4-port 1 Gb BASE-T (OCP3) |
| Expansion | PCIe Gen5 + OCP 3.0 slots |
| Power Supplies | 2 × 800 W Flex-Slot, hot-swappable |
| Management | HPE iLO 6 |
| Security | Silicon Root of Trust, Secure Boot, TPM |
| Form Factor | 1U Rack-mount |
| Operating Temperature | Standard data-center range |
| Warranty | 3 years (parts, labor, next-business-day on-site) |
