| Primary Information |
|---|
| System Type | Server Barebone |
| Cabinet Form Factor | 2U |
| Processor / Type | Xeon |
| Processor / Manufacturer | Intel |
| Processor / Max Supported Qty | 2 |
| Mainboard / Chipset Type | Intel C612 |
| RAM / Technology | DDR4 |
| RAM / Total Slots Qty | 16 |
| RAM / Max Supported Size | 2 TB |
| Hard Drive / Size | 2.5" |
| Hard Drive / Interface Type | SAS/SATA |
| Hard Drive / Bays Qty | 12 |
| Storage Controller Type | PCI Express; SAS 3 |
| RAID Level | RAID 0, 1, 10 |
| Data Link Protocol | Gigabit Ethernet |
| Power / Device Type | Power Supply - Redundant |
| Interfaces & Connections | 8 SAS3 (12Gbps) ports, 2 RJ45 Gigabit Ethernet LAN ports 1 RJ45 Dedicated IPMI LAN port, 1 external QSFP Infiniband connector , 2 USB 3.0 ports (rear), 1 VGA port, 1 Fast UART 16550 port / 1 Header (internal) |
| Expansion Bays Total (Free) | 12 Hot-swap 2.5" SAS (8) / SATA (4) HDD Bays |
| Expansion Slots Total (Free) | 1 PCI-E 3.0 x16 slot 1 PCI-E 3.0 x8 slot |
| Model | CSE-217HD+-R1K28B |
| Width | 17.25 Inch |
| Depth | 28.75 Inch |
| Height | 3.47 Inch |
| Enclosure Color | Black |
| Features | 1. Dual socket R (LGA 2011) supports Intel Xeon processor E5-2600 and E5-2600 v2 family 2. Up to 1TB ECC LRDIMM, 512GB ECC RDIMM, up to 1866MHz; 16x DIMM sockets 3. 1x PCI-E 3.0 x16 Low-profile slot; 1x PCI-E 3.0 x8 Low-profile slot 4. Intel i350-AM2 Dual port GbE LAN 5. Integrated IPMI 2.0 with KVM and Dedicated LAN 6. 12x Hot-swap 2.5" SAS/SATA HDD Bays 7. LSI 3008 SAS3 controller (8 ports) + 2 SATA3 + 2 SATA2; RAID 0,1,10 8. 1280W Redundant Power Supplies Platinum Level (94%) |
| RoHS | Y |
