| Primary Information |
|---|
| System Type | Server Barebone |
| Cabinet Form Factor | 1U |
| Processor / Type | Xeon |
| Processor / Manufacturer | Intel |
| Processor / Max Supported Qty | 2 |
| Mainboard / Chipset Type | Intel C621 |
| RAM / Technology | DDR4 |
| RAM / Total Slots Qty | 12 |
| RAM / Max Supported Size | 3 TB |
| Hard Drive / Size | 2.5" |
| Hard Drive / Interface Type | SAS/SATA |
| Hard Drive / Bays Qty | 8 |
| Storage Controller Type | PCI Express |
| RAID Level | RAID 0, 1, 5, 10 |
| Data Link Protocol | Gigabit Ethernet |
| Power / Device Type | Power Supply - Redundant |
| Interfaces & Connections | 8 SATA3 (6 Gbps) ports, 2 RJ45 Gigabit Ethernet ports 1 RJ45 Dedicated IPMI LAN port, 4 USB 3.0 ports (rear), 1 VGA port, 2 SuperDOM (Disk on Module) ports. |
| Expansion Bays Total (Free) | 8 Hot-swap 2.5" SAS/SATA drive bays |
| Expansion Slots Total (Free) | 2 PCI-E 3.0 x16 (FHHL) slots 1 PCI-E 3.0 x8 (LP) slot 1 PCI-E 3.0 x16 for Add-on-Module (AOM) 1 PCI-E 3.0 x4 NVMe M.2 slot |
| Model | CSE-113AC2-R706WB2 |
| Width | 17.2 Inch |
| Depth | 23.5 Inch |
| Height | 1.7 Inch |
| Enclosure Color | Black |
| Features | 1. Dual socket R3 (LGA 2011) supports Intel Xeon processor E5-2600 v4/ v3 family; QPI up to 9.6GT/s 2. Up to 2TB ECC 3DS LRDIMM , up to DDR4- 2400MHz ; 16x DIMM slots 3. 1x PCI-E 3.0 x16 Low-profile slot 4. Intel i350 Dual port GbE LAN 5. Integrated IPMI 2.0 with KVM and Dedicated LAN 6. 4x 2.5" Hot-swap SAS3 drive bays 7. Broadcom 3108 SAS3 controller; RAID 0, 1, 10, 5, 6 8. 1000W Redundant Power Supplies Titanium Level (96%) |
| RoHS | Y |
