SUPERMICRO COMPUTER SYS-1029P-MT Server Barebones View larger

SUPERMICRO COMPUTER SYS-1029P-MT Server Barebones

SYS-1029P-MT

New

CSE-118GQPTS-R2K05P2-Server Barebone-1U-Xeon-Gigabit Ethernet-Power Supply-Redundant-2 Hot-swap 2.5 SAS/SATA drive bays,2 Internal 2.5 drive bays,Support 1x M.2 2242/2260/2280 Support M.2...
×




Detailed Specifications

Primary Information
System TypeServer Barebone
Cabinet Form Factor1U
Processor / TypeXeon
Processor / ManufacturerIntel
Processor / Max Supported Qty2
Mainboard / Chipset TypeIntel C621
RAM / TechnologyDDR4
RAM / Total Slots Qty12
RAM / Max Supported Size3 TB
Hard Drive / Size2.5"
Hard Drive / Interface TypeSAS/SATA
Hard Drive / Bays Qty2
Storage Controller TypePCI Express; M.2
RAID LevelRAID 0, 1, 5, 10
Data Link ProtocolGigabit Ethernet
Power / Device TypePower Supply - Redundant
Power / Provided (W)600 Watt
Interfaces & Connections4 SATA3 (6Gbps) ports, 2 RJ45 10GBase-T ports 1 RJ45 Dedicated IPMI LAN port, 2 USB 3.0 ports (rear), 1 VGA port, 1 Fast UART 16550 header.
Expansion Bays Total (Free)2 Hot-swap 2.5" SAS/SATA drive bays, 2 Internal 2.5" drive bays, Support 1x M.2 2242/2260/2280 Support M.2 SATA and NVMe
Expansion Slots Total (Free)4 PCI-E 3.0 x16 slots - supporting 4 NICs which includes 2x GPUDirect RDMA
ModelCSE-118GQPTS-R2K05P2
Width17.2 Inch
Depth35.2 Inch
Height1.7 Inch
Enclosure ColorBlack
Features1. Supports up to 4 NVIDIA P100 SXM2 GPUs with up to 80 GB/s GPU-GPU NVIDIA NVLINK Interconnection 2. Optimized for NVIDIA GPUDirect RDMA 3. Dual Socket P (LGA 3647) support 2nd Gen Intel Xeon Scalable processors (Cascade Lake/Skylake) 4. 12 DIMMs; up to 3TB 3DS ECC DDR4-2933MHz RDIMM/LRDIMM, Supports Intel Optane DCPMM 5. 2 PCI-E 3.0 x16 slots, 2 PCI-E 3.0 x16 LP slots 6. 2 Hot-swap 2.5" SAS/SATA drive bays, 2 Internal 2.5" drive bays, Optional NVMe U.2 drive option 7. 2x 10GBase-T LAN ports via Intel X540 8. Support 1x M.2 2242/2260/2280, Support M.2 SATA and NVMe 9. 7 Heavy duty 4cm counter-rotating fans with air shroud & optimal fan speed control 10. 2000W Redundant Power Supplies Titanium Level (96%)
RoHSY

Special Feature
COOInquire
TAA complianceInquire

UNSPSC Code
UNSPSC Code43211502
