| Primary Information |
|---|
| System Type | Server Barebone |
| Cabinet Form Factor | 1U |
| Processor / Type | Xeon |
| Processor / Manufacturer | Intel |
| Processor / Max Supported Qty | 2 |
| Mainboard / Chipset Type | Intel C621 |
| RAM / Technology | DDR4 |
| RAM / Total Slots Qty | 12 |
| RAM / Max Supported Size | 3 TB |
| Hard Drive / Size | 2.5" |
| Hard Drive / Interface Type | SAS/SATA |
| Storage Controller Type | M.2; PCI Express |
| RAID Level | RAID 0, 1, 5, 10 |
| Data Link Protocol | Gigabit Ethernet |
| Power / Device Type | Power Supply - Redundant |
| Interfaces & Connections | 4 SATA3 (6Gbps) ports, 2 RJ45 10GBase-T ports 1 RJ45 Dedicated IPMI LAN port, 2 USB 3.0 ports (rear), 1 VGA port, 1 Fast UART 16550 header. |
| Expansion Bays Total (Free) | 2 Hot-swap 2.5" SAS/SATA drive bays, 2 Internal 2.5" drive bays, Support 1x M.2 2242/2260/2280 Support M.2 SATA and NVMe |
| Expansion Slots Total (Free) | 4 PCI-E 3.0 x16 (FHFL) slots - supporting up to 4 GPUs 1 PCI-E 3.0 x16 (LP) slot 1 PCI-E 3.0 x8 (LP) slot Drive Bays |
| Model | CSE-118GQETS-R2K05P2 |
| Width | 17.2 Inch |
| Depth | 35.2 Inch |
| Height | 1.7 Inch |
| Enclosure Color | Black |
| Features | 1. Supports up to 4 Active/Passive Cooling NVIDIA GPUs in 1U 2. Dual Socket P (LGA 3647) support 2nd Gen Intel Xeon Scalable processors (Cascade Lake/Skylake) 3. 12 DIMMs; up to 3TB 3DS ECC DDR4-2933MHz RDIMM/LRDIMM, Supports Intel Optane DCPMM 4. 4 PCI-E 3.0 x16 (FHFL), 1 PCI-E 3.0 x16 (LP) and 1 PCI-E 3.0 x8 (LP) 5. 2 Hot-swap 2.5" U.2 NVMe drive bays, 2 Internal 2.5" SATA drive bays 6. Support 1x M.2 2242/2260/2280, Support M.2 SATA and NVMe 7. 2x 10GBase-T LAN ports via Intel X540 8. 9 Heavy duty 4cm counter-rotating fans with air shroud & optimal fan speed control 9. 2000W Redundant Power Supplies Titanium Level (96%) |
| RoHS | Y |
