| Primary Information |
|---|
| System Type | Server Barebone |
| Cabinet Form Factor | 1U |
| Processor / Type | Xeon |
| Processor / Manufacturer | Intel |
| Processor / Max Supported Qty | 2 |
| Mainboard / Chipset Type | Intel C612 |
| RAM / Technology | DDR4 |
| RAM / Total Slots Qty | 16 |
| RAM / Max Supported Size | 2 TB |
| Hard Drive / Size | 2.5" |
| Hard Drive / Interface Type | SATA III 6Gb/s |
| Hard Drive / Bays Qty | 2 |
| Storage Controller Type | PCI Express |
| RAID Level | RAID 0, 1, 5, 6, 10, 50, 60 |
| Data Link Protocol | Gigabit Ethernet |
| Power / Device Type | Power Supply - Redundant |
| Power / Provided (W) | 400 Watt |
| Power / Voltage Required | 100-240V, 50-60Hz, 6-3A |
| Interfaces & Connections | 10x SATA3 (6Gbps) ports, 2x RJ45 10GBase-T ports, 1x RJ45 Dedicated IPMI LAN port, 2x USB 3.0 ports (via header), 4x USB 2.0 ports (rear), 1x VGA port, 1x Header. |
| Expansion Bays Total (Free) | 2x 2.5" Fixed drive bays with bracket |
| Expansion Slots Total (Free) | 2x PCI-E 3.0 x16 Full-height, Half-length slots |
| Model | CSE-514-R400W |
| Width | 17.2 Inch |
| Depth | 16.9 Inch |
| Height | 1.7 Inch |
| Enclosure Color | Black |
| Features | Dual socket R3 (LGA 2011) supports Intel Xeon processor E5-2600 v4/ v3 family; QPI up to 9.6GT/s 2. Up to 2TB ECC 3DS LRDIMM , up to DDR4- 2400MHz ; 16x DIMM slots 3. 2x PCI-E 3.0 x16 (FHHL) slots 4. 2x 2.5" Fixed drive bays w/ bracket 5. Intel X540 Dual port 10GBase-T 6. Integrated IPMI 2.0 and KVM with Dedicated LAN 7. I/O ports: 2x SuperDOM, 1x VGA, 1x COM, 2x USB 3.0, 4x USB 2.0 8. 400W Redundant Power Supplies Gold Level; BBP option |
| RoHS | Y |
