Detailed Specifications
Fortinet FGR-70F-3G4G-BDL-809-12
The FortiGate Rugged 70F-3G4G is built for industrial, transportation, and energy sector environments where network stability is critical. Combining durable hardware with FortiOS-driven advanced security, it ensures uninterrupted, secure networking. With VPN IPSec throughput up to 6.5 Gbps, SD-WAN optimization, and 3G/4G LTE support, it is ideal for remote and harsh deployments.
Features :
Designed for extreme operating conditions, this appliance has a rugged, fanless, and compact rail-mount design for secure placement in industrial cabinets, vehicles, or challenging locations. It supports a wide DC power input range, enabling flexible deployment without risk of downtime. With integrated LTE, it offers secure wireless connectivity where wired internet is unavailable, and SD-WAN helps optimize link performance and cost efficiency.
Advanced Options :
FortiOS provides comprehensive NGFW capabilities including intrusion prevention, web filtering, application control, SSL inspection, antivirus, and threat intelligence services. With 11 Gigabit Ethernet ports and a 1 million session capacity, the Rugged 70F-3G4G maintains consistent throughput for industrial automation, transportation monitoring, and multi-site communications.
Product Key Features
- Rugged, fanless design for harsh and remote environments
- 11× Gigabit Ethernet ports for versatile connectivity
- Integrated 3G/4G LTE for wireless WAN access
- Advanced threat protection powered by FortiOS
- VPN IPSec throughput up to 6.5 Gbps with SD-WAN optimization
- Industrial-grade temperature tolerance from -40°C to 75°C
Reliability & Performance :
Engineered for all-weather, continuous operation, the FortiGate Rugged 70F-3G4G uses a fanless architecture for silent reliability and fewer failure points. It supports a wide +/−12V to 125V DC power input range and consumes just 19.9W. Its LTE modules are hot-swappable, and the compact 3.2 × 4.4 × 4.8 inch footprint ensures easy installation in tight spaces. Built to withstand extreme heat, cold, and vibration, it is a resilient choice for mission-critical field networking.
Key Features :
- Industrial-grade next-generation firewall
- Fanless, rugged chassis with rail-mount capability
- 3G/4G LTE wireless WAN support
- SD-WAN for optimized multi-link performance
- High-speed VPN IPSec up to 6.5 Gbps
- Wide DC input (+/−12V to 125V) for flexible deployment
Specifications :
| Specification | Details |
|---|
| Model Number | FGR-70F-3G4G-BDL-809-12 |
| Brand | Fortinet |
| Product Type | Security Appliance |
| Ports | 11 × Gigabit Ethernet |
| Wireless Connectivity | 3G / 4G LTE |
| VPN IPSec Throughput | 6.5 Gbps |
| IPS Throughput | 975 Mbps |
| Concurrent Sessions | 1,000,000 |
| New Sessions/sec | 35,000 |
| Power Input | +/-12V to 125V DC |
| Max Power Consumption | 19.9W |
| Dimensions (H×W×D) | 3.2 in × 4.4 in × 4.8 in |
| Weight | 1.2 kg (est.) |
| Operating Temperature | -40°C to 75°C |
| Form Factor | Fanless, rail-mountable |
