Fortinet FG-1001F FortiGate 1001F Security Appliance

Fortinet FG-1001F

FortiGate 1000F Security Appliance - High-Density, Front-to-Back Cooling

Purpose-built for high-bandwidth enterprise and carrier-grade data centers, the FortiGate 1000F packs a colossal 198 Gbps firewall throughput and ASIC-powered ultra-low latency into a 2U chassis with front-to-back airflow. Dual 480 GB SSDs plus a TPM module safeguard logs and cryptographic secrets, while an expansive interface mix×from 100 GE QSFP28 to multi-gig RJ45×provides unmatched deployment flexibility.

Features :

Leveraging seventh-generation NP7 network processors and CP9 content processors, the FG-1001F delivers 19 Gbps IPS and 13 Gbps threat-protection performance with deterministic, micro-second latency. Interface density includes 2 × QSFP28 (100/40 GE), 8 × SFP28 / SFP+ (25/10 GE), 16 × SFP+ (10 GE), 8 × RJ45 (1/10 GE), plus dedicated MGMT and HA ports×ideal for leaf-spine aggregation, east-west segmentation, and high-speed service-provider edges.

Advanced Options :

With support for roughly 7.5 million concurrent sessions and 650 k new sessions/sec, the appliance scales seamlessly during traffic spikes. Dual hot-swap PSUs and redundant fans maximize uptime, while Security Fabric integration enables unified policy, zero-trust segmentation, and AI-powered analytics across multi-cloud and OT environments. Optional FortiManager & FortiAnalyzer extend centralized orchestration and compliance reporting.

Product Key Features

• Peak firewall throughput: 198 Gbps
• High-density ports: 100 GE, 25 GE, 10 GE, 1 GE, MGMT & HA
• Dual 480 GB SSDs with TPM for secure, high-capacity logging
• 2U rack-mount chassis with front-to-back airflow
• NP7 & CP9 ASIC acceleration for ultra-low latency

---

Reliability & Performance :

ASIC off-loading guarantees line-rate inspection even with TLS decryption enabled, while front-to-back cooling aligns with modern hot-aisle / cold-aisle data-center layouts. Average power draw is a modest 215 W, scaling to a 415 W max under full load. Hot-plug power supplies and fans, plus extensive hardware certifications (ICSA, USGv6, CE, FCC), deliver carrier-class resilience and compliance.

Key Features :

• 198 Gbps firewall | 19 Gbps IPS | 13 Gbps threat protection
• 7.5 M concurrent & 650 k new sessions/sec
• Dual 480 GB SSD storage + TPM security
• 2U front-to-back airflow; dual hot-swap PSUs
• Integrated NGFW, SSL inspection, SD-WAN & ZTNA

Specifications :

Specification	Details
Model Number	FG-1001F
Product Series	FortiGate 1000F
Firewall Throughput (UDP IPv4)	Up to 198 Gbps (1518/512/64-byte)
IPS Throughput	19 Gbps
Threat Protection	13 Gbps
Concurrent Sessions	≈ 7.5 Million
New Sessions / Sec	≈ 650,000
Interfaces	2 × QSFP28 (100/40 GE), 8 × SFP28/SFP+ (25/10 GE), 16 × SFP+ (10 GE), 8 × RJ45 (1/10 GE), 1 × MGMT, 1 × HA, USB, Console
On-Board Storage	2 × 480 GB SSD
Hardware Acceleration	NP7 (network) & CP9 (content) ASICs
Form Factor & Cooling	2U Rack-Mount; front-to-back airflow
Power Consumption	Avg 215 W / Max 415 W
Power Supply	Dual hot-plug redundant PSUs (included)
Operating Conditions	0-40 °C; 10-90 % non-condensing
Security & Compliance	TPM, ICSA (FW/IPS/AV/SSL-VPN), USGv6, CE, FCC
