Fortinet FG-61F-USG FortiGate 61F TAA Compliant Security Appliance View larger
Previous Next

Fortinet FG-61F-USG FortiGate 61F TAA Compliant Security Appliance

New

Compact, fanless TAA-compliant NGFW with enterprise threat protection
×




  • New

Detailed Specifications

Fortinet FortiGate 61F TAA-Compliant

Silent Fanless Desktop Next-Gen Firewall – Secure, Government-Ready Protection

The Fortinet FortiGate 61F (FG-61F-USG) is a compact, TAA-compliant next-generation Firewall purpose-built for U.S. government and secure enterprise environments. Delivering advanced threat protection, high throughput, and silent fanless operation, it ensures reliable and compliant security in space-constrained or sensitive deployments.

Features :

Powered by Fortinet’s FortiASIC SoC4 architecture, the 61F delivers fast Firewall , VPN, IPS, application control, and secure SD-WAN in a single device. Its completely fanless desktop form factor ensures noise-free operation, making it ideal for quiet office spaces, mobile units, and sensitive field installations.

Advanced Options :

The appliance features 10× GE RJ-45 ports (including 2 WAN, 1 DMZ, 5 internal, and 2 FortiLink), plus console and USB-A interfaces for versatile connectivity. Performance is strong across workloads—Firewall up to 10 Gbps, IPS at 1.4 Gbps, NGFW at 1 Gbps, IPsec VPN at 6.5 Gbps, and SSL inspection at ~750 Mbps. With 128 GB onboard SSD storage, it supports robust logging and analytics, all manageable via FortiOS, FortiCloud, and enterprise tools such as FortiManager.

Product Key Features

  • TAA-compliant, U.S. government-approved secure firewall appliance
  • Fanless, silent desktop design with external power adapter
  • High throughput with FortiSOC-4/SoC4 chip and NGFW capabilities
  • Comprehensive threat protection: IPS, SSL inspection, SD-WAN, antivirus
  • 128 GB onboard SSD for log storage and device performance

Reliability & Performance :

Designed for secure operations, the FortiGate 61F operates silently while consuming only 17–19 W of power via an external AC adapter. Its small footprint (1.5″ × 8.5″ × 6.3″) and lightweight build (~1 kg) make it easy to deploy in tight spaces or mobile setups. Compliance with TAA and multiple global certifications ensures it meets stringent regulatory and operational demands while delivering dependable high-speed security.

Key Features :

  • TAA-compliant Firewall appliance for U.S. government
  • Fanless, silent desktop form factor
  • High performance across Firewall , IPS, VPN, NGFW workloads
  • Full-spectrum threat protection: NGFW, SSL inspection, SD-WAN
  • 128 GB SSD for enhanced logging and system durability

Specifications :

SpecificationDetails
Model Number FG-61F-USG (TAA-compliant)
Type Desktop Next-Gen Firewall (NGFW), TAA-compliant
Processor Fortinet SoC4 (FortiASIC-based SOC4)
Form Factor Fanless desktop, silent operation
Internal Storage 128 GB SSD
Interfaces 2× GE WAN, 1× GE DMZ, 5× GE internal, 2× FortiLink, 1× console RJ-45, 1× USB-A
Firewall Throughput 10 Gbps (UDP 1518 / 512 / 64 bytes)
IPS Throughput 1.4 Gbps
NGFW Throughput 1 Gbps
Threat Protection Throughput 700 Mbps
IPsec VPN Throughput 6.5 Gbps
SSL VPN Throughput 900 Mbps
SSL Inspection Throughput ~750 Mbps
Concurrent Sessions (TCP) 700,000
New TCP Sessions per Second 35,000
Virtual Domains (VDOMs) 10
Fortinet Ecosystem Support FortiSwitch (up to 16), FortiAP (up to 30), FortiTokens (up to 500)
Power Consumption ~17–19 W
Power Supply External AC adapter, 100–240 V AC
Dimensions (HxWxD) 1.5″ × 8.5″ × 6.3″ (38 × 216 × 160 mm)
Weight ~1 kg (2.2 lbs)
Operating Temp / Humidity 0–40 °C / 10–90% non-condensing
Certifications & Compliance TAA, ICSA (Firewall, IPSec, Antivirus, SSL-VPN), UL, CB, FCC, CE, etc.
Management Interfaces FortiOS, FortiCloud, FortiManager, FortiAnalyzer, Web UI, CLI
