Fortinet FGR-70G-5G-DUAL-BDL-950-36 FortiGate Security Appliance

Fortinet FortiGate Rugged 70G-5G-Dual

Industrial-Grade 5G-Enabled Next-Gen Firewall - High-Performance Security for OT & Remote Environments

The Fortinet FortiGate Rugged 70G-5G-Dual security appliance is a compact, industrial-grade firewall engineered for operational technology (OT) networks and remote deployments. Designed to thrive in extreme conditions, it combines ultra-fast 5G broadband connectivity and enterprise-level security services with centralized cloud management. With its ruggedized build, advanced threat protection, and a bundled 3-year support package, it ensures resilient, high-performance operations in challenging industrial and field environments.

Features :

The unit integrates a powerful FortiASIC SP5 processor inside a DIN-rail mountable, IP40-rated chassis, making it ideal for deployment in control rooms, mobile enclosures, or industrial branch sites. Offering multiple wired interfaces (4× GE RJ-45 LAN, 2× GE RJ-45 WAN, 2× SFP), alongside a dual embedded 5G modem with GPS and extensive band support, it ensures versatile and redundant connectivity options. External antennas, Bluetooth LE, and expansive environmental tolerance further enhance its adaptability for mission-critical networks.

Advanced Options :

Security performance is exceptional, with up to 8 Gbps firewall throughput, 7.1 Gbps IPsec VPN, and robust SSL inspection capabilities, complemented by advanced intrusion prevention and AI-backed threat protection. The appliance scales seamlessly to support large deployments with up to 64 FortiAPs, 500 FortiTokens, and 24 FortiSwitches. Its redundant DC power inputs and fanless design contribute to reliability, while hardware-based TPM and rugged housing provide both cyber and physical defense layers.

Product Key Features

• DIN-rail mountable, IP40-rated rugged design for harsh environments
• Integrated dual 5G modem with GPS and extensive cellular band support
• High-performance SP5 ASIC delivering multi-Gbps firewall and VPN throughput
• Scales for distributed deployments with FortiAP, FortiToken, and FortiSwitch integration
• Dual redundant DC power inputs for enhanced uptime
• Cloud-managed with AI-powered threat protection and virtual domain support

---

Reliability & Performance :

Built for mission-critical environments, the FortiGate Rugged 70G-5G-Dual meets MIL-grade and IP40 certifications, capable of operating from −40 °C to +75 °C at altitudes up to 10,000 ft. Its redundant dual DC power inputs (12-125 V) protect against electrical instability, and the fanless design ensures low maintenance and silent operation. Additional features like Trusted Platform Module (TPM) support, hardened housing, and comprehensive environmental resilience make it a powerhouse of reliability for industrial and remote deployments.

Key Features :

• DIN-rail mountable, IP40-rated rugged construction
• Dual 5G modems with GPS and broad band support
• 8 Gbps firewall , 7.1 Gbps VPN, and high-speed SSL inspection
• Supports 64 FortiAPs, 500 FortiTokens, and 24 FortiSwitches
• Dual redundant DC power for operational continuity

Specifications :

Specification	Details
Model Number	FGR-70G-5G-Dual (BDL-950-36 package with 3-year support)
Type	Ruggedized security appliance (Next-Gen firewall )
Processor	FortiASIC SP5
Form Factor	DIN-rail mountable, indoor, IP40
Wired Interfaces	4× GE RJ-45 LAN, 2× GE RJ-45 WAN, 2× SFP ports
Wireless Modules	Dual embedded 5G modem, GPS, Bluetooth LE
Power	Redundant dual DC inputs (12-125 V), 2-pin terminal block
firewall Throughput	IPv4 8 Gbps (UDP 1518/512/64 bytes)
VPN Throughput (IPsec)	7.1 Gbps (512-byte)
SSL Inspection	1.3 Gbps / 1.4 M concurrent sessions / 715 CPS
IPS/NGFW/Threat Protect Throughput	2.5 Gbps / 1.5 Gbps / 1.1 Gbps
Capacity	1.4 M concurrent TCP sessions; 85k new sessions/s; 5,000 policies
Virtual Domains	Up to 10 (default and maximum)
Management Support	FortiCloud, AI-powered FortiGuard security, Zero Trust, SD-WAN
Environmental Tolerance	-40 °C to +75 °C; up to 10,000 ft altitude; 5-95% non-condensing
Weight / Dimensions	4.1 × 4.8 × 5.5 in (139 × 104 × 122 mm); weight not specified
Certifications	IP40, IEC 61850-3, IEEE 1613, IEC/EN 62368-1, FCC, CE, UL, CB, RoHS
