MikroTik RBD52G-5HacD2HnD-TC-US

hAP ac² Dual-Band Desktop Wireless Access Point (US Version)

The MikroTik RBD52G-5HacD2HnD-TC-US (hAP ac²) is a versatile dual-band desktop access point and router designed for small offices, homes, and SOHO environments. With simultaneous dual-band wireless, five Gigabit ports, and full RouterOS functionality,it offers a complete wired and wireless networking solution in a compact footprint.

Features

Built for environments that demand strong wireless and wired connectivity, the hAP ac² delivers concurrent 2.4 GHz and 5 GHz Wi-Fi with support for modern 802.11ac standards. The five Gigabit Ethernet ports allow multiple high-speed LAN connections, while PoE in and out provides streamlined power management for connected devices like access points or IP phones.

Advanced Options

Powered by a quad-core 716 MHz CPU and 128 MB of RAM, the device is responsive under multitasking network loads. It runs RouterOS with a Level 4 license, enabling sophisticated features including routing, firewalling, bandwidth shaping, VPN tunnels, and centralized management.

.

Product Key Features

• • Dual-band Wi-Fi (2.4 GHz & 5 GHz) with 802.11ac for high-speed wireless

  • Compact tower-style desktop design with integrated antenna

  • Includes 5× Gigabit Ethernet ports for fast wired connections

  • Supports passive PoE input and output on port 1

  • Runs RouterOS Level 4 for advanced routing, firewall, and VPN capabilities

  • US-licensed version for FCC-compliant wireless operation

Reliability & Performance

The RBD52G-5HacD2HnD-TC-US is engineered for 24/7 operation with a fanless cooling design, stable throughput, and robust firmware. Its integrated dual-chain MIMO radios ensure consistent wireless performance across devices, and its US-certified radio allows legal operation on US channels and power limits. The unit's tower-style form factor makes it easy to place in office or home setups.

Key Features :

• Dual-band 2.4 GHz + 5 GHz wireless with 802.11a/b/g/n/ac

• 5 × Gigabit Ethernet ports

• Passive PoE input (on port 1) and output (on port 5)

• Quad-core 716 MHz CPU with 128 MB RAM

• RouterOS with Level 4 license

• Compact desktop tower enclosure

• US version - FCC certified

Specification	Details
Model Number	RBD52G-5HacD2HnD-TC-US (hAP ac²)
Product Type	Dual-Band Desktop Wireless Access Point
Wireless Frequency	2.4 GHz & 5 GHz (simultaneous)
Wireless Standards	802.11a/b/g/n/ac
Ethernet Ports	5 × 10/100/1000 Mbps RJ-45
PoE Support	In (on port 1), Out (on port 5, passive)
CPU	IPQ-4018, Quad-Core, 716 MHz
RAM	128 MB
Storage	16 MB Flash
Operating System	RouterOS, License Level 4
Antenna	Dual-chain integrated antennas
Enclosure	Desktop tower plastic case
Dimensions	120 × 100 × 30 mm
Weight	~300 g
