Detailed Specifications
Rackmount Router Board with 5x Fast Ethernet & 5x Gigabit Ports
The MikroTik RB2011UiAS-RM is a versatile rackmount RouterBoard designed for professional and enterprise-grade network environments. Offering ten Ethernet ports, touchscreen diagnostics, and expanded storage options, it's built to handle dynamic workloads in access and edge routing scenarios.
Features
The RB2011UiAS-RM is a more advanced version of the RB2011 series, offering a combination of 5 Fast Ethernet and 5 Gigabit Ethernet ports to accommodate a mix of legacy and high-speed network devices. It also includes a USB port and microSD slot, allowing for external file storage, boot options, or backup configurations. The integrated touchscreen LCD provides easy status updates and system metrics without needing a separate console.
Advanced Options
Powered by a 600 MHz Atheros AR9344 CPU with 128 MB of RAM, this unit delivers responsive performance for routing, filtering, VPN tunneling, and traffic shaping. The included RouterOS Level 5 license enables advanced features like EoIP tunnels, MPLS, VLANs, and hotspot management.
Product Key Features
10-port router with a combination of 5 Fast Ethernet and 5 Gigabit Ethernet ports
Includes an LCD touchscreen display for real-time monitoring and diagnostics
Features USB port and microSD slot for additional storage or configuration
Passive PoE output on port 10 to power compatible MikroTik devices
Runs RouterOS Level 5, supporting advanced networking, firewall, VPN, and hotspot features
1U metal rackmount enclosure with passive cooling for silent operation
Reliability & Performance
Built for durability, the RB2011UiAS-RM is housed in a sturdy 1U metal rackmount enclosure and passively cooled for silent, maintenance-free operation. It supports passive PoE output on port 10, making it a practical power source for wireless access points or other MikroTik RouterBOARDs. Ideal for SMBs, branch offices, and advanced lab setups.
Key Features :
5 × Fast Ethernet ports
5 × Gigabit Ethernet ports
LCD touchscreen for system monitoring
Passive PoE output on port 10
USB port and microSD slot for storage
Atheros AR9344 600 MHz CPU
128 MB RAM / 128 MB NAND storage
RouterOS Level 5 license
1U rackmount metal enclosure
Fanless, silent cooling
| Specification | Details |
|---|
| Model Number | RB2011UiAS-RM |
| Product Type | Rackmount Ethernet Router |
| CPU | Atheros AR9344, 600 MHz |
| RAM | 128 MB DDR2 |
| Storage | 128 MB NAND |
| Ethernet Ports | 5 × Fast Ethernet, 5 × Gigabit Ethernet |
| PoE Output | Yes, passive PoE on port 10 |
| USB Port | Yes (Type-A) |
| microSD Slot | Yes |
| LCD Display | Yes (touchscreen) |
| Operating System | RouterOS, License Level 5 |
| Enclosure | 1U Rackmount metal case |
| Cooling | Passive (fanless) |
| Dimensions | 443 × 92 × 44 mm |
| Weight | ~600 g |
