MikroTik RB1100Dx4 13-Port Gigabit Router Dude Edition

New

MikroTik RB1100Dx4 13-Port Gigabit Router Dude Edition
×




  • New

Detailed Specifications

MikroTik RB1100Dx4

(RB1100AHx4) Dude Edition – 13‑Port Gigabit Router (1U Rackmount)

The MikroTik RB1100Dx4 Dude Edition is a high‑performance, rack‑mountable router designed for enterprise, ISP, and data‑center environments. Featuring 13 Gigabit ports, robust hardware encryption, and a grounded Dude monitoring platform, it’s tailored for heavy workloads, secure VPNs, and out‑of‑the‑box manageability.

Features

Powered by a quad‑core 1.4 GHz Annapurna Labs Alpine AL21400 CPU, the RB1100Dx4 delivers exceptional routing performance with up to 7.5 Gbps throughput It offers 13 Gigabit Ethernet interfaces plus an SFP bypass for resilient network paths. IPsec hardware acceleration reaches 2.2 Gbps, ideal for secure site‑to‑site tunnels with low latency .

Advanced Options

The Dude Edition comes pre-installed with a 60 GB M.2 SSD and has two additional SATA and two M.2 slots, enabling on-device storage for the Dude server, logging, proxy caching, or virtualization environments DC (-48 V) and AC power inputs with failover ensure maximum uptime. The 1U rack chassis with passive cooling and dual PSUs provides silent reliability.

Product Key Features

  •  Quad‑core 1.4 GHz Annapurna AL21400 CPU—up to 7.5 Gbps routing throughput

  •  13× Gigabit Ethernet ports + 1× SFP bypass on ports 11/12

  •  Hardware IPsec acceleration—up to 2.2 Gbps AES128

  •  Includes 60 GB M.2 SSD, plus 2× SATA and 2× M.2 slots for storage expansion

  •  Dual AC & DC (-48 V telecom) + PoE‑IN redundancy, rackmount form, passive cooling

  •  Built‑in Dude server on included SSD for network monitoring out of the box

Reliability & Performance

Rated with an MTBF of 1.6 million hours, this drive is built for constant uptime in high-demand server environments. It supports hot-plug functionality, allowing IT teams to replace or scale storage without downtime. Its enterprise-class shock and vibration resistance enhances longevity, while efficient power usage keeps operational costs low in energy-conscious data centers.

Key Features :

  • High Throughput & VPN Ready: Supports 7.5 Gbps full-wire routing and 2.2 Gbps AES128 VPNs. Storage-Rich: 60 GB SSD, dual SATA/M.2—perfect for integrated Dude monitoring or caching. Redundant Power: Dual AC/DC, PoE‑IN, temperature/voltage monitoring for reliability. Silent & Durable: Fanless metal rackmount design rated for –40 °C to +70 °C with MTBF ~200,000 hrs

SpecificationDetails
Model Number RB1100Dx4 / RB1100AHx4 Dude Edition
Product Type Rackmount Gigabit Router
CPU Annapurna AL21400, 4× Cortex‑A15 @1.4 GHz
RAM 1 GB DDR
Storage 128 MB NAND + 60 GB M.2 SSD
Storage Expansion 2× SATA 3 + 2× M.2 slots
Ethernet Ports 13× 10/100/1000 Mbps
SFP Ports N/A (SFP bypass on Eth11/12)
Hardware Encryption AES128/256 IPsec acceleration up to 2.2 Gbps
USB None
Serial Port RS‑232 console
Power Inputs 2× AC IEC, 2× DC terminal (20‑57 V / -48 V), PoE‑IN
Power Consumption 25 W idle, 33 W max
Cooling Passive fanless
Dimensions 443 × 148 × 44 mm (1U)
MTBF & Temp Range ~200,000 h; –40 °C to +70 °C
Monitoring Voltage, current, PCB temp
RouterOS License Level 6
Certifications CE, EAC, RoHS, IP20
Included Accessories Rack ears, SATA cables, SSD, IEC cords, screw kit
