MikroTik CSS610-1Gi-7R-2S+OUT netPower Lite 7R Outdoor PoE Switch View larger

MikroTik CSS610-1Gi-7R-2S+OUT netPower Lite 7R 8-Port Outdoor Switch

CSS610-1Gi-7R-2S+OUT

New

MikroTik CSS610-1Gi-7R-2S+OUT netPower Lite 7R 8-Port Outdoor Switch
×




crs310 1g 5s 4sout, MIKROTIK router, Gigabit Ethernet router, CSS610 1Gi 7R 2SOUT datasheet, netpower lite 7r, CSS610-1Gi-7R-2S OUT review, CSS610-1Gi-7R-2S OUT manual, 8-Port Outdoor router Switch, Reverse PoE switch

Detailed Specifications

MikroTik CSS610-1Gi-7R-2S+OUT netPower Lite 7R 8-Port Outdoor Switch with 7-Port Reverse PoE 2-Port SFP+

Overview :

With netPower Lite 7R switch you can forget about expensive GPON base stations and optical splitters. This switch is a part of our GPEN concept – aimed to bring the speed and versatility of fiber networking while using the advantages of Ethernet. It is an easy to deploy, low-cost way for any ISP to deliver the Internet to individual apartments.

With this switch you won’t have to worry about power issues, as there are many options. netPower Lite 7R has 7 reverse PoE ports. Depending on your setup, netPower can draw the necessary power even from a single client! Ethernet port 8 can power other PoE capable devices with the same voltage as applied to the unit. There is also a DC jack and a 2-pin terminal for alternative powering.

The outdoor enclosure allows you to install this switch in all kinds of environments – from damp attics to elevator shafts and different poles with hose clamps. netPower Lite 7R has a non-blocking throughput of 28 Gbps, switching capacity of 56 Gbps and forwarding rate of 41.7 Mpps.

Specifications :

Product code CSS610-1Gi-7R-2S+OUT
Switch chip model 88E6193X
Dimensions 304 x 212 x 71 mm
Operating System SwitchOS Lite
Storage size 64 KB
Storage type FLASH
MTBF Approximately 200'000 hours at 25C
Tested ambient temperature -40°C to 70°C
