MikroTik CRS326-24G-2S+IN 24x Gigabit Ports, 2x SFP+ Cloud Router Switch

New

MikroTik CRS326-24G-2S+IN 24x Gigabit Ports, 2x...

×




  • New

Detailed Specifications

MikroTik CRS326-24G-2S+IN

CRS326-24G-2S+IN Cloud Router Switch – 24x Gigabit Ethernet Ports, 2x 10G SFP+, Fanless Desktop Layer 3 Managed Switch

The MikroTik CRS326-24G-2S+IN Cloud Router Switch is a cost-effective, fanless managed switch designed for networks that require a balance of high port density, 10G uplinks, and silent operation. With 24 Gigabit ports, 2 SFP+ slots, and dual OS support, it's ideal for small business networks, enterprise edge environments, or advanced home setups.

Features

Engineered for flexibility, the CRS326-24G-2S+IN supports both RouterOS and SwOS, letting users choose between a full-featured Layer 3 OS or a simple Layer 2 switching interface. Powered by a 98DX3236 switching chip and a single-core 800 MHz CPU, it can handle VLANs, ACLs, port isolation, traffic shaping, and basic routing.

Advanced Options

The SFP+ cages provide high-speed 10G uplinks, enabling fast backbone or server connections. Its passive cooling ensures silent operation, while the durable metal chassis and compact form factor make it suitable for desktops, cabinets, or wall-mounted installations.

Product Key Features

    • 24x 10/100/1000 Mbps Gigabit Ethernet ports for flexible wired networking

    • 2x SFP+ 10G ports for high-speed fiber uplinks

    •  Dual operating system: RouterOS Level 5 and SwOS for advanced or simplified management

    • Fanless passive cooling design for silent and energy-efficient operation

    •  Ideal for enterprise LANs, access layer switching, or home lab environments

    •  Compact metal desktop or wall-mountable chassis

Reliability & Performance

This model is designed for quiet environments without sacrificing reliability. With passive cooling, no moving parts, and robust internal components, the CRS326 offers longevity and stable performance. Its SwOS/RouterOS dual-boot capability lets you switch between simple switch configs and complex network functions depending on your use case.

Key Features :

  • 24 × Gigabit RJ45 Ethernet ports

  • 2 × 10G SFP+ fiber ports

  • Dual boot OS: RouterOS Level 5 / SwOS

  • Single-core 800 MHz CPU

  • 512 MB RAM and 16 MB Flash

  • Passive, fanless cooling for silent operation

  • Desktop-sized metal chassis

  • Supports VLANs, ACLs, port mirroring, traffic control

  • Ideal for LAN aggregation and enterprise edge switching

  • Wall-mount or flat desktop deployment

SpecificationDetails
Model Number CRS326-24G-2S+IN
Product Type Cloud Router Switch (Managed L3)
CPU 800 MHz single-core
RAM 512 MB
Storage 16 MB Flash
Operating System RouterOS Level 5 / SwOS
Ethernet Ports 24 × 10/100/1000 Mbps RJ45
SFP+ Ports 2 × 10G SFP+
Switching Capacity 56 Gbps
Forwarding Rate 41.7 Mpps
Cooling Passive (fanless)
Power Input 100–240V AC (via adapter)
Power Consumption ~21 W max
Dimensions 11.2" × 5.7" × 1.7" (285 × 145 × 44 mm)
Weight ~2.2 lbs (1.0 kg)
Operating Temperature -20°C to +60°C (-4°F to +140°F)
