| Primary Information |
|---|
| System Type | Server |
| Model | CSE-515M-R000NP2 |
| Cabinet Form Factor | Rack-Mountable |
| Processor / Manufacturer | Intel |
| Processor / Type | Xeon |
| Processor / Clock Speed | 2.1 GHz |
| Max Turbo Frequency | 3.2 GHz |
| Processor / Number | D-2733N |
| Multi-Core Technology | 8-Core |
| Cache Memory Installed Size | 15 MB |
| Mainboard / Chipset Type | Intel SoC Platform |
| RAM / Technology | DDR4 |
| RAM / Memory Speed | 2667 MHz |
| RAM Form Factor | DIMM |
| RAM / Total Slots Qty | 4 |
| RAM / Max Supported Size | 512 GB |
| Hard Drive / Size | 2.5" |
| Hard Drive / Interface Type | SATA III; PCI Express |
| Hard Drive / Bays Qty | 2 |
| Networking Type | Ethernet |
| Controller Interface Type | PCI Express 4.0 x16 |
| Data Link Protocol | Gigabit Ethernet |
| Video Output Type | VGA |
| Power / Device Type | Power Supply |
| Power / Redundant Capable | Yes |
| Power / Installed Qty | 2 |
| Power / Provided (W) | 600 Watt |
| Power / Voltage Required | -44--65Vdc |
| Interfaces & Connections | 1 RJ45 Dedicated IPMI LAN port; 2 RJ45 10Gbe Intel X550; 2 SFP28 25Gbe Intel SOC; 4 RJ45 1Gbe Intel I350; 1 VGA port(s); USB |
| Front I/O Ports | USB, RJ45,VGA,SFP28 |
| Expansion Slots Total (Free) | 1 PCIe Gen 4 x16 FHFL slot(s) |
| Width | 17.2 Inch |
| Depth | 15.7 Inch |
| Height | 1.7 Inch |
| Weight | 18 lbs. |
| Features | Intel Xeon Processor D-2733NT, CPU TDP 80W; Up to 256GB Registered ECC RDIMM, DDR4-2667MHz; Up to 512GB RDIMM LRDIMM, DDR4-2667MHz, in 4 DIMM slots; 2x Internal 2.5" drive bays(2x PCIe 4.0 NVMe x8 SlimSAS and 1x OCuLink options); 4x GbE, 2x 25G SFP28 and 2x 10G Base-T; 1x M.2 M-Key 2242/2280 (SATA/PCIe 3.0 x4); 5x 40x56mm Hot-swap Counter-rotation PWM Fans; Redundant 600 W, -48 Vdc |
| Enclosure Color | Silver |
| Min Operating Temperature | 0 Celsius |
| Max Operating Temperature | 40 Celsius |
| Humidity Range Operating | 8% to 90% (non-condensing) |
