HPE R0X36A

CX 6400 Series 3000 W Power Supply (with C20 Inlet Adapter)

The HPE Aruba R0X36A delivers a robust 3000 W power supply solution for Aruba CX 6400 modular switches, ideal for deployments featuring power-hungry PoE line cards and high-speed aggregation modules. With hot-swap and redundancy support, it ensures uninterrupted operation and energy-efficient performance in enterprise and data center environments.

Features

Engineered for the 5-slot Aruba CX 6400 family, the R0X36A slides into the power supply bays and supports both single and dual PSU configurations. Its wide input range (110-240 VAC) and included C20 inlet adapter provide flexible deployment globally. Achieving 80 Plus Platinum efficiency, it minimizes waste heat and power loss×crucial for high-density PoE and uplink scenarios

Advanced Options

Supporting the chassis' full power demands×from Class 6 PoE modules to QSFP28 uplink cards×the redundant design ensures seamless swap-outs without downtime.

Product Key Features

• High-output 3000 W power supply to support PoE, uplink, and high-density modules

• Hot-swappable and supports redundant configurations

• Dual-voltage input: 110-127 V or 200-240 V AC at 50/60 Hz

• Includes IEC C20 inlet adapter for standard rack power

• 80 Plus Platinum certified for high energy efficiency

• Designed exclusively for Aruba CX 6400 modular chassis (6405/6410)

Reliability & Performance

Built for mission-critical environments, the R0X36A supports hot-swapping in dual-PSU setups, enabling service or replacement without impacting operation. Its high efficiency lowers energy costs and thermal load, while integrated thermal monitoring and chassis airflow handling maintain safe operation under full load.

Key Features (Bullet List)

• • 3000 W output via 54 V DC for Aruba line cards

  • Hot-swappable and redundant capabilities

  • Dual-voltage AC input (110-240 V, 50/60 Hz)

  • Includes IEC C20 inlet adapter

  • 80 Plus Platinum efficiency rating

  • Designed for Aruba CX 6400 modular chassis

Specification	Details
Model Number	R0X36A
Product Type	Modular AC Power Supply
Output Power	3000 W
Output Voltage	54 V DC
Input Voltage Range	110-127 VAC / 200-240 VAC
Frequency	50 / 60 Hz
Inlet Type	IEC C20 (adapter included)
Efficiency Rating	80 Plus Platinum
Hot-Swappable	Yes
Redundancy Support	Yes (with ≥2 PSUs)
Compatible Chassis	Aruba CX 6400 (6405 / 6410)
Dimensions (H×W×D)	1.6 × 4.1 × 13 in (40.6 × 104.1 × 330 mm)
Weight	~4.4 lb / 2.0 kg
Certifications	RoHS compliant
Warranty	HPE Limited Lifetime (chassis installed)
