Detailed Specifications
Vertiv VA4N2100 Rpdu Rack Transfer Switch Monitored Unit Level 20A 120V 1.9KW
Overview :
The Vertiv Geist Rack Transfer Switch VA4N2100 is a versatile rack power distribution unit (rPDU) with a transfer switch. It is a 20A, 120V, single phase rack PDU with 10 NEMA 5-20R outlets and a max power capacity of 1.9kW. The RTS provides redundant power to single corded devices and helps ensure continuity in the event of power loss. It can quickly detect power loss on the main source and automatically switch it to the secondary source within 4 to 8 milliseconds. The Interchangeable Monitoring Device provides unit level remote power monitoring, as well as environmental monitoring capabilities with the addition of optional sensors. This TAA-Compliant Vertiv RTS comes with a standard three-year warranty, which can be extended to five years if registered within 120 days after purchase.
Specification :
| Product Name |
Rpdu Rack Transfer Switch Monitored Unit Level 20A 120V 1.9KW |
| Manufacturer Part Number |
VA4N2100 |
| Product Type |
PDU |
| Phase |
Single Phase |
| Receptacle Type |
NEMA 5-20R |
| Product Family |
N |
| TAA Compliant |
Yes |
| PDU Type |
Switched Auto Transfer Switch |
| Remote Outlet Switching |
No |
| Mounting Orientation |
Horizontal |
| Power Rating (Watt) |
1900 W |
| Product Color |
Black |
| Receptacle Detail |
10 x NEMA 5-20R |
| Rack Height |
1U |
| Plug / Connector Type |
NEMA 5-20P |
| Input Voltage Range |
100 V AC - 120 V AC |
| Input Current |
20 A |
| Input Voltage |
120 V |
| Environmentally Friendly |
Yes |
| Output Voltage Range |
100 V AC - 120 V AC |
| Network (RJ-45) |
Yes |
| Plug / Connector Detail |
2 x NEMA 5-20P |
| Country of Origin |
United States |
| Height |
1.7" |
| Width |
17" |
| Depth |
18" |
| Product Series |
N |
| Product Model |
AN03E1R5-10S203- 2ST5ST5A011-D |
| Limited Warranty |
5 Year |
| USB |
Yes |
| Modem (RJ-11) |
No |
| Serial Port |
Yes |
| Modem (RJ-12) |
Yes |
| Modem (RJ-22) |
No |
| Number of Cord / Cable |
2 |
