The QNAP INCTS-H1887XU-RP-E2334-16G-US is a high-capacity, enterprise-grade 2U, 18-bay rackmount NAS powered by an Intel® Xeon® E-2334 processor and equipped with 16 GB ECC DDR4 memory to deliver reliable, high-throughput storage performance. Featuring twelve 3.5″ bays and six dedicated 2.5″ slots, this hybrid chassis supports both HDDs and SSDs, enabling cost-efficient bulk storage and high-speed flash caching. Running QNAP INCZFS-based QuTS hero OS, it ensures data integrity, inline deduplication, and robust snapshot support. Whether for file servers, virtualization, VDI, or backup systems, this NAS combines enterprise features with optimized scalability, backed by a strong warranty and government-grade compliance.
Built for modern hybrid storage workflows, the TS-H1887XU-RP-E2334-16G supports a powerful Intel® Xeon® E-2334 (4 cores/8 threads at 3.4GHz, boosting up to 4.8GHz) with AES-NI encryption acceleration, delivering enterprise-level CPU performance. Its 16 GB ECC DDR4 memory (user-upgradeable to 128 GB) guards against bit-flips, ensuring data fidelity in critical use cases such as virtualization or database hosting.
The internal storage architecture supports 12x 3.5″ SATA drives plus 6x 2.5″ SATA bays for SSDs, letting you configure high-capacity volume pools alongside SSD caching acceleration to maximize both IOPS and capacity efficiency. QuTS hero's ZFS design supports features such as inline deduplication, compression, SnapSync real-time backups, and SSD anti-wear leveling (QSAL).
Intel® Xeon® E-2334 (4C/8T, up to 4.8 GHz) with AES-NI
16 GB ECC DDR4 RAM (expandable to 128 GB)
Hybrid storage: 12x 3.5″ + 6x 2.5″ SATA bays
SSD caching acceleration via rear SSD bays
QuTS hero (ZFS) for dedupe, snapshots, SnapSync, QSAL
Two 10 GbE and two 2.5 GbE RJ45 ports onboard
Three PCIe Gen4 slots for expansion
Dual-redundant 550W PSU (hot-swappable)
2U rackmount chassis, 14.9 kg net weight
Designed for mission-critical deployments, the TS-H1887XU-RP provides a balance of redundancy, speed, and integrity. Powered by a robust Xeon platform with ECC RAM, it is built for consistency under sustained workloads. The QuTS hero OS, built on enterprise-class ZFS, offers data-reliability features like checksums, scrubbing, and crash protection, optimizing performance and minimizing storage risk.Expandable PCIe Gen4 slots support advanced capabilities like 25GbE networking, M.2 SSD cache, or GPU pass-through for virtualization. With RAID 0/1/5/6/10/50/60 and triple-parity options, as well as remote backup and cloud sync support, the TS-H1887XU-RP is ideal for demanding enterprise, virtualization, and backup environments.
Intel Xeon E-2334 CPU with AES-NI
16 GB ECC DDR4 RAM (upgradeable to 128 GB)
12 x 3.5″ HDD bays + 6 x 2.5″ SSD bays
Supports SSD caching acceleration
Dual 10 GbE + Dual 2.5 GbE RJ45 ports
3x PCIe Gen4 slots for expansion
QuTS hero ZFS operating system
Redundant hot-swappable 550 W power supplies
HDD/SSD hot-swappable bays
Enterprise RAID modes including triple parity
| Specification | Description |
|---|---|
| Model Number | TS-H1887XU-RP-E2334-16G-US |
| CPU | Intel® Xeon® E-2334 (4C/8T, 3.4 GHz base, 4.8 GHz turbo) |
| Memory | 16 GB ECC DDR4 (1 x 16 GB), up to 128 GB (4 x 32 GB) |
| Flash | 5 GB onboard dual-boot OS ignition |
| Drive Bays | 12 x 3.5″ SATA + 6 x 2.5″ SATA (hot-swappable) |
| Interface | SATA III 6 Gb/s |
| Cache Support | SSD cache acceleration on rear SSD bays |
| Network Ports | 2 × 2.5 GbE + 2 × 10 GbE RJ45 (multi-gig supported) |
| PCIe Slots | 3 × PCIe Gen4 (2 × x4, 1 × x8) |
| Power Supplies | Dual redundant 550 W, hot-swappable |
| Dimensions (HxWxD) | 88.6 × 432 × 511.2 mm |
| Weight (Net / Gross) | ≈14.9 kg / ≈19 kg |
| Operating Temp / Humidity | 0-40 °C, 5-95% RH non-condensing |
| OS | QuTS hero (ZFS) / QTS optional |
