Black Box LPS500A-MM-SC-R2 10/100/1000BT PoE Media Converter MMSC View larger

Black Box LPS500A-MM-SC-R2 10/100/1000BT PoE Media Converter MMSC

LPS500A-MM-SC-R2

New

Black Box LPS500A-MM-SC-R2 10/100/1000BT PoE Media Converter MMSC
×




dc supplies, power over ethernet (poe), Black Box Media Converter, Media Conversion Device, 10/100/1000BT PoE Media Converte, Gigabit Ethernet PoE Converter, LPS500A-MM-SC-R2, Black Box LPS500A-MM-SC-R2, LPS500A-MM-SC-R2 Media Converter, Multi-Mode SC Connector

Detailed Specifications

Black Box LPS500A-MM-SC-R2 10/100/1000BT PoE Media Converter MMSC

Overview :

The unmanaged PoE PSE Media Converter is a next generation Ethernet converter offering one gigabit per second performance. It is used in Ethernet copper to fiber media conversion applications over long distances.

The media converter delivers one (10M/100M/1G) RJ-45 with one PoE port (supports 802.3 af up to 15.4 W) and one GbE SC or LC port. The converter provides high hardware performance and environment flexibility for Ethernet applications.

Three models are available:

  • LPS500A-MM-LC-R2: TP to Multimode Fiber Media Converter with RJ-45 and LC connectors
  • LPS500A-MM-SC-R2: TP to Multimode Fiber Media Converter with RJ-45 and SC connectors

Specifications :

Product Name 10/100/1000BT PoE Media Converter MMSC
Product Type Transceiver/Media Converter
Ethernet Technology Gigabit Ethernet
Number of PoE (RJ-45) Ports 1
Number of SC Ports 1
Media Type Supported Twisted Pair

Optical Fiber
Fiber Mode Supported Multi-mode
Total Number of Ports 2
SC Port Type Duplex
PoE Port Type PSE
Form Factor Wall Mountable
Network Technology 1000Base-SX

10/100/1000Base-T
Maximum Distance Supported 1804.46 ft
Power Source Power Supply
Fiber Optic Cable Standard 50/125 µm

62.5/125 µm

100/140 µm
Height 6.2"
Width 1.5"
Depth 5.2"
Product Model LPS500A-MM-SC-R2
Power Consumption 65 W
