Detailed Specifications
Ruckus ICX7150-24P-2X10G 24 ports managed switch rack mountable Multi 10 GbE Uplinks
Overview
The RUCKUS ICX7150-24P-2X10G is a 24-port PoE+ gigabit access switch designed for access-layer deployments in campus wiring closets or branch offices where you need PoE to power APs/cameras and high-bandwidth uplinks. It offers 24 × 10/100/1000 Mbps RJ-45 PoE+ ports with a 370 W PoE budget, plus uplink flexibility via 2 × 1 Gb RJ-45 uplinks, 2 × 1 Gb SFP, and 2 × 10 Gb SFP+ stacking/uplink ports (upgradable to 4×10 Gb SFP+ with license). In real-world terms: plug 24 end-devices (IP cameras, PoE APs, VoIP phones) into the RJ-45 ports, then use the 10 Gb uplinks to handle aggregation to the core/aggregation layer, or stack multiple units into a single logical switch for simplified management.budget, plus uplink flexibility via 2 × 1 Gb RJ-45 uplinks, 2 × 1 Gb SFP, and 2 × 10 Gb SFP+ stacking/uplink ports (upgradable to 4×10 Gb SFP+ with license). In real-world terms: plug 24 end-devices (IP cameras, PoE APs, VoIP phones) into the RJ-45 ports, then use the 10 Gb uplinks to handle aggregation to the core/aggregation layer, or stack multiple units into a single logical switch for simplified management.
Key Features
24 × 1 Gb RJ-45 PoE+ ports supporting up to 370 W total PoE budget.
2 × 10 Gb SFP+ uplinks (stacking/uplink) built-in, with license option to upgrade to 4 × 10 Gb SFP+ uplinks
Full stacking support: up to 12 switches per stack, with aggregate stacking bandwidth up to ~480 Gbps.
Layer 3 static routing (RIP) support out of the box; licence upgrade options available for advanced L3 (OSPF, VRRP, PIM) on higher SKUs.
Fan-less or quiet mode design (depending on configuration/model) suitable for noise-sensitive environments like retail floors or conference rooms.
Specifications
| Specification | Detail |
|---|
| Brand | RUCKUS |
| Part Number | ICX7150-24P-2X10G |
| Product Type | Managed Access Switch (24 × 1 Gb PoE+ RJ-45 ports + multi-10 Gb uplinks) |
| Key Specification | Port Configuration: 24 × 10/100/1000 Mbps RJ-45 PoE+ + 2×1Gb RJ-45 uplinks + 2×1Gb SFP + 2×10 Gb SFP+ (upgradeable to 4×10Gb) |
| Key Specification | PoE Budget: 370 W total for the 24 PoE+ ports |
| Key Specification | Switching Capacity / Stack Bandwidth: Up to ~132 Gbps switching capacity; stacking up to 12 units, up to ~480 Gbps aggregated stack bandwidth |
| Management | CLI, Web GUI, SNMP, USB-C console, Out-of-band RJ-45 management port |
| Power Requirements | Internal AC power supply, single-unit (no redundant PSUs) |
| Dimensions & Weight | Approx. 17.3 in (W) × 11.0 in (D) × 1.7 in (H) / ~10.9 lbs (~4.9 kg) – based on family datasheet size for 24-port models |
