Detailed Specifications
Ruckus ICX7150-48ZP-E8X10GR-RMT3 – Managed PoE+ Ethernet Switch
Overview :
The Ruckus ICX7150-48ZP-E8X10GR-RMT3 is a high-performance, rack-mountable managed Ethernet switch designed for enterprise and campus environments. It features 48 ports: 16 Multigigabit (100/1000/2.5G) PoE+ ports and 32 Gigabit PoE+ ports, delivering a total PoE budget of up to 1,440W. The switch supports Layer 3 features such as OSPF, VRRP, PIM, and PBR, providing advanced routing capabilities for complex network architectures. With 8 SFP+ 10GbE uplink/stacking ports, it offers high-speed connectivity for backbone and aggregation layers. Designed for reliability and scalability, it includes redundant, hot-swappable power supplies and fans, ensuring continuous operation in demanding environments. The ICX7150-48ZP-E8X10GR-RMT3 is ideal for organizations requiring robust, high-density PoE+ solutions with advanced Layer 3 features and flexible uplink options.
Key Features :
16 Multigigabit (100/1000/2.5G) PoE+ ports
32 Gigabit PoE+ ports
8 SFP+ 10GbE uplink/stacking ports
1,440W total PoE budget
Layer 3 features: OSPF, VRRP, PIM, PBR
Specifications :
| Specification | Details |
|---|
| Brand | Ruckus Networks |
| Part Number | ICX7150-48ZP-E8X10GR-RMT3 |
| Product Type | Managed PoE+ Ethernet Switch (Z-Series) |
| Total Ports | 48 (16 Multigigabit PoE+ + 32 Gigabit PoE+) |
| Uplink Ports | 8 x SFP+ 10GbE (stacking/uplink) |
| PoE Budget | Up to 1,440W |
| Layer 3 Features | OSPF, VRRP, PIM, PBR |
| Switching Capacity | Up to 160 Gbps |
| Forwarding Rate | Up to 120 Mpps |
| Form Factor | 1U Rack-mountable |
| Cooling | Fan-assisted, hot-swappable |
| Power Supply | Dual redundant, hot-swappable |
| Management Ports | 1 x RJ-45 Serial Console, 1 x RJ-45 Out-of-Band Management, 1 x USB Type-C, 1 x USB (for external file storage) |
| Airflow | Front to Back |
| Dimensions (W x D x H) | 17.5 x 11.8 x 1.7 inches (445 x 300 x 44 mm) |
| Weight | 18.6 lbs (8.4 kg) |
