Detailed Specifications
Ruckus ICX7150-48P-4X10GR – 48-Port PoE+ Switch with 4x 10G SFP+
Overview :
The Ruckus ICX7150-48P-4X10GR is a high-performance, stackable managed switch designed for enterprise networks requiring robust connectivity and Power over Ethernet Plus (PoE+) support. Equipped with 48 Gigabit Ethernet ports and 4 10-Gigabit SFP+ uplink ports, it offers flexible deployment options for high-density environments. The switch delivers up to 370W of PoE+ power, enabling the direct connection of powered devices such as IP phones, wireless access points, and security cameras. Advanced Layer 3 features, including OSPF, VRRP, PIM, and PBR, provide enhanced routing capabilities for complex network architectures. Its compact 1U form factor ensures efficient use of rack space, making it suitable for data centers, wiring closets, and edge deployments. The ICX7150-48P-4X10GR is also compatible with Ruckus' Campus Fabric technology, allowing for scalable and resilient network designs.
Key Features :
48 x 10/100/1000 Mbps PoE+ ports
4 x 10G SFP+ uplink ports
370W PoE+ power budget
Advanced Layer 3 features: OSPF, VRRP, PIM, PBR
1U rack-mountable form factor
Specifications :
| Specification | Details |
|---|
| Brand | Ruckus |
| Part Number | ICX7150-48P-4X10GR |
| Product Type | Managed Switch |
| Ports | 48 x 10/100/1000 Mbps PoE+ |
| Uplink Ports | 4 x 10G SFP+ |
| PoE+ Power Budget | 370W |
| Layer 3 Features | OSPF, VRRP, PIM, PBR |
| Form Factor | 1U Rack-mountable |
| Switching Capacity | 180 Gbps |
| Forwarding Rate | 134 Mpps |
| MAC Address Table Size | 16,384 |
| Stacking Bandwidth | 480 Gbps |
| Power Consumption (Idle) | 32W |
| Power Consumption (Full Load) | 472W |
| Operating Temperature | 0°C to 40°C |
| Dimensions (H x W x D) | 1.73 x 17.3 x 11.5 inches |
| Weight | 10.5 lbs |
