Detailed Specifications
Ruckus ICX8200-48P – 48-Port Managed PoE+ Switch
Overview :
The Ruckus ICX8200-48P is a high-performance, stackable Layer 2/3 managed switch designed for enterprise campus networks. It features 48 Gigabit Ethernet (10/100/1000 Mbps) RJ45 ports with Power over Ethernet Plus (PoE+) support, delivering up to 370 W of power. This makes it suitable for powering devices such as IP phones, wireless access points, and security cameras. The switch also includes 4 SFP28 ports for 25 GbE uplinks or stacking, providing high-speed connectivity for backbone or inter-switch links. With a switching capacity of 296 Gbps and a forwarding capacity of 220 million packets per second, it ensures efficient data handling. The ICX8200-48P supports advanced features like VXLAN, Layer 2/3 routing, and secure network segmentation, making it ideal for modern, wireless-first, and IoT-enabled environments. Its compact 1U form factor allows for easy deployment in standard server racks.
Key Features :
48 PoE+ Ports: Powers devices up to 370 W total.
4× 25 GbE SFP28 Ports: High-speed uplinks and stacking.
296 Gbps Switching Capacity: Efficient data handling.
220 Mpps Forwarding Capacity: High-performance packet processing.
Advanced Layer 2/3 Features: Supports VXLAN and secure segmentation.
Specifications :
| Specification | Details |
|---|
| Brand | Ruckus Networks |
| Part Number | ICX8200-48P |
| Product Type | Managed PoE+ Switch |
| Ports | 48× 10/100/1000 Mbps RJ45 |
| PoE Budget | 370 W |
| Uplink Ports | 4× SFP28 (25 GbE) |
| Switching Capacity | 296 Gbps |
| Forwarding Capacity | 220 Mpps |
| Form Factor | 1U Rack-Mountable |
| Stacking Capability | Yes, up to 12 units |
| Management | Web GUI, CLI, SNMP |
| Layer 2 Features | VLAN, STP, Link Aggregation |
| Layer 3 Features | Routing, VXLAN, ACLs |
| Redundancy | Hot-swappable fans and power supplies |
| Dimensions (H x W x D) | 1.73 x 17.3 x 10.5 inches |
| Weight | 11.9 lbs |
