Detailed Specifications
Ruckus ICX7150-48ZP-E2X10G – 48-Port Managed PoE+ Switch with Multigigabit Uplinks
Overview :
The Ruckus ICX7150-48ZP-E2X10G is a high-performance managed Ethernet switch designed for enterprise access networks. It features 48 ports, including 16 Multigigabit (100/1000/2500 Mbps) Power over HDBaseT (PoH) ports and 32 Gigabit Ethernet (10/100/1000 Mbps) PoE+ ports, providing flexible connectivity options for various devices. The switch offers a total PoE budget of 740W, ensuring sufficient power delivery to connected devices. With 2 x 10G SFP+ and 6 x 1G SFP uplink ports, it supports high-speed data transmission and stacking capabilities. The ICX7150-48ZP-E2X10G is suitable for deployment in enterprise environments requiring robust performance, scalability, and power over Ethernet capabilities. Its compact form factor and efficient design make it an ideal choice for modern network infrastructures.
Key Features :
16 x 2.5G PoH ports for high-power device support
32 x 1G PoE+ ports with 740W total PoE budget
2 x 10G SFP+ and 6 x 1G SFP uplink ports
Layer 3 features including OSPF, VRRP, PIM, and PBR
Front-to-back airflow with hot-swappable fan module
Specifications
| Specification | Details |
|---|
| Brand | Ruckus Networks |
| Part Number | ICX7150-48ZP-E2X10G |
| Product Type | Managed PoE+ Switch |
| Ports | 48 (16 x 2.5G PoH, 32 x 1G PoE+) |
| Uplink Ports | 2 x 10G SFP+, 6 x 1G SFP |
| PoE Budget | 740W |
| Switching Capacity | 304 Gbps |
| Forwarding Rate | 226 Mpps |
| MAC Address Table Size | 16,384 |
| DRAM | 1 GB |
| Flash Memory | 2 GB |
| Power Supply | 1 x 920W RPS20-E PSU |
| Fan Module | 1 x Hot-swappable |
| Airflow Direction | Front-to-back |
| Form Factor | 1U Rack-mountable |
| Operating Temperature | 0°C to 40°C |
| Dimensions (H x W x D) | 1.75" x 17.3" x 12.0" |
| Weight | 9.5 lbs |
