Ruckus ICX7650-48ZP-E-RMT3 48-Port 24XMG PoE Switch with 1 PSU

New

48-port multigig PoE+ L3 switch with remote support
×




  • New

Detailed Specifications

Ruckus ICX 7650-48ZP-E-RMT3

48-Port Multigigabit PoE+ Layer 3 Switch – Enterprise-Grade with 1 PSU & 3 Years Remote Support

The Ruckus ICX 7650-48ZP-E-RMT3 is a managed Layer 3 access switch designed for enterprises, campuses, and top-of-rack deployments. Featuring multigigabit ports, robust PoE+ delivery, and high-bandwidth QSFP uplinks, it provides resilient scalability for high-density Wi-Fi and security environments. Bundled with 3 years of 24×7 remote support, this model ensures consistent uptime and peace of mind for critical operations.

Overview :

This switch offers 24× multigigabit RJ-45 ports (1/2.5/5/10 GbE) for modern high-demand devices such as Wi-Fi 6/6E access points and IoT systems, alongside 24× Gigabit RJ-45 ports for standard client or endpoint connectivity. Uplinks are supported via four QSFP slots, configurable as either 2×100 GbE or 4×40 GbE active ports, enabling flexible stacking or high-speed aggregation.

The unit includes one hot-swappable 1000 W AC power supply and a fan system with front-to-back airflow, supporting efficient operations and easy maintenance. The “RMT3” naming denotes the inclusion of a 3-year enterprise-grade 24×7 remote support package for troubleshooting and SLA-backed service assurance.

Engineered on the ICX 7650 platform, it delivers next-generation features such as Campus Fabric architecture, MACsec encryption, Layer 3 routing (OSPF, BGP, VRF with license), and Energy Efficient Ethernet. Perfect for mission-critical edge deployment, this switch combines high performance with comprehensive resiliency.

Product Key Features

  • 24 × multigig RJ-45 (1/2.5/5/10 GbE) + 24 × Gigabit RJ-45 with PoE+
  • Supports high PoE budget with PoE+/PoH (up to 1500 W with dual PSU)
  • 4 × QSFP uplinks for 40/100 GbE stacking or aggregation
  • Includes 1 × 1000 W AC PSU and fan module, front-to-back airflow
  • Advanced Layer 3 features, MACsec security, and Campus Fabric
  • Includes 3 years of 24×7 remote enterprise support

Reliability & Performance :

The ICX 7650-48ZP-E-RMT3 offers 1.128 Tbps switching capacity and 839 Mpps forwarding rate for uncompromising network throughput. With PoE+ power delivery supporting next-gen access points and devices, it ensures consistent performance at the edge. Hot-swappable PSU and fan options maximize uptime, while QSFP uplinks enable adaptable inter-switch or aggregation connectivity. Enterprise features such as Energy Efficient Ethernet, MACsec, and advanced L3 routing protocols strengthen operational resilience for secure, large-scale environments.

Key Features :

  • 48-port architecture: 24 × multigig + 24 × Gigabit with PoE+
  • Up to 1,500 W PoE budget with dual PSUs; includes 1 × 1000 W PSU
  • 4 × QSFP ports configurable for 2 × 100GbE or 4 × 40GbE
  • Non-blocking 1.128 Tbps switching capacity / 839 Mpps forwarding
  • Hot-swappable PSU and front-to-back airflow design
  • Supports Campus Fabric, MACsec encryption, and advanced Layer 3
  • Bundled with 3 years of 24×7 remote support

Specifications :

SpecificationDetails
Model Number ICX 7650-48ZP-E-RMT3
Product Type Layer 3 Managed Multigigabit PoE+ Switch
Fixed Multigig Ports 24 × 1/2.5/5/10 GbE RJ-45
Fixed Gigabit Ports 24 × 1 GbE RJ-45
Uplink/Stacking Ports 4 × QSFP (configurable: 2 × 100GbE or 4 × 40GbE)
Power Supply (Included) 1 × 1000 W AC PSU (hot-swappable)
Redundancy Option Supports second PSU/fan module
PoE Budget Up to 1,500 W (with dual PSU); partial with single PSU
Switching Capacity 1.128 Tbps
Forwarding Rate 839 Mpps
Stacking Support Yes – up to 12 switches
Layer 3 Features Static, RIP, OSPF, BGP, VRF (licensed)
Key Technologies Campus Fabric, MACsec, Energy Efficient Ethernet
Airflow Direction Front-to-back
Management Interfaces OOB Ethernet, USB-C/A, RJ-45 Console
Remote Support 3 years 24×7 support included
Energy Efficiency IEEE 802.3az (EEE)
Security Features MACsec Encryption
Warranty Support + hardware replacement per vendor policy
