Detailed Specifications
RUCKUS ICX7450-48 – Ethernet Switch / 336 Gb/s Switching Capacity
Overview :
The RUCKUS ICX7450-48 is a fixed-form 1 GB access switch designed for enterprise deployments, enabling network teams to deliver dense 1 GbE connectivity while preserving uplink and stacking scalability. It features 48 RJ-45 10/100/1000 Mb/s ports and supports modular uplinks including 10 GbE and 40 GbE, allowing upgrades as traffic grows. Its stacking architecture supports up to 12 switches with an aggregate stack bandwidth of 960 Gb/s, making it suitable in campus wiring closets, aggregation layers or small data-centre top-of-rack installations. The unit supports hot-swappable power supplies and fans, reversible airflow, and advanced Layer 2/3 feature sets including OSPF, BGP and VRF, enabling consistent management alongside wired and wireless infrastructure.
Key Features :
48 × 10/100/1000 Mb/s RJ-45 ports in 1 RU form-factor
Modular uplink slots supporting up to 12 × 10 GbE or 3 × 40 GbE QSFP+
Stackability of up to 12 units with up to 960 Gb/s stacking bandwidth
Dual hot-swappable power/fan assemblies with reversible airflow
Specifications :
| Specification | Detail |
|---|
| Brand | RUCKUS |
| Part Number | ICX7450-48 |
| Product Type | Ethernet switch |
| Switching Capacity | 336 Gb/s maximum |
| 1 GbE RJ-45 Ports | 48 ports |
| 1 GbE SFP Ports | 4 ports maximum |
| 10 GbE SFP+ Ports | 12 ports maximum |
| 10 GbE RJ-45 Ports | 12 ports maximum |
| 40 GbE QSFP+ Ports | 3 ports maximum |
| Stack Members | Up to 12 switches |
| Aggregate Stack Bandwidth | 960 Gb/s |
| PoE/PoE+ Support | No (for this model) |
| Dimensions (W×D×H) | 17.3 in × 15.5 in × 1.7 in |
| Weight | 14.55 lbs |
| Reversible Airflow | Yes |
| Layer 3 Features | Static/RIP/OSPF, BGP, VRF |
