Ruckus ICX7450-48-E 48 Port PoE Switch with SFP+ and QSFP+ Ports View larger
Previous Next

Ruckus ICX7450-48-E 48-Port Managed Switch with SFP+ and QSFP+ Uplinks

New

Enterprise-Class Gigabit Switch with High-Speed 10GbE and 40GbE Expansion
×




  • New

Detailed Specifications

Ruckus ICX7450-48-E

48-Port Managed Switch with SFP+ and QSFP+ Uplinks

The Ruckus ICX7450-48-E is a high-performance, enterprise-class managed switch designed to deliver speed, scalability, and reliability for demanding networks. With 48 non-PoE Gigabit Ethernet ports and modular slots supporting both 10GbE SFP+ and 40GbE SFP+ uplinks, this switch is optimized for campus, enterprise, and data center environments that require flexibility and low-latency connectivity.

Expanded Overview :

Offering 48 non-PoE Gigabit Ethernet ports, the ICX7450-48-E supports dense user connectivity while easing integration with advanced devices and applications. Its modular uplink architecture enables support for both SFP+ (10GbE) and SFP+ (40GbE) modules, ensuring scalable bandwidth to address evolving traffic needs.

Advanced Layer 3 routing protocols—including dynamic routing—enable efficient traffic management and enterprise-grade performance across the network. Designed with resiliency in mind, it features hot-swappable power supplies and fan trays, minimizing downtime and making maintenance straightforward.

The ICX7450 family scales effortlessly with stacking support for up to 12 switches, unifying management under one logical system and maximizing network performance. This makes the ICX7450-48-E a reliable and forward-looking choice for enterprises seeking agility and high availability in networking.

Product Key Features

  • 48 x 1GbE RJ-45 non-PoE ports
  • 3 modular slots for flexible uplinks
  • Supports 10GbE SFP+ and 40GbE QSFP+ modules
  • Stacking scalability up to 12 switches
  • Hot-swappable redundant power supplies and fan trays
  • Advanced Layer 3 features and enterprise-grade security
  • Centralized management via SmartZone, ZoneDirector, or Cloud

Reliability & Performance :

The ICX7450-48-E is built for reliable, high-availability environments. With redundant, hot-swappable hardware, it ensures uninterrupted operations and simplified serviceability. Flexible modular uplinks enable high-speed aggregation through 10GbE or 40GbE connectivity. Security is bolstered with enterprise-level features such as ACLs, 802.1X, and traffic protection. Centralized management options—including CLI, Web GUI, SNMP, and Ruckus SmartZone, ZoneDirector, or Cloud—support seamless monitoring and configuration across modern IT infrastructures.

Key Features :

  • 48 x 1GbE RJ-45 non-PoE access ports
  • 3 modular uplink slots for SFP+ (10GbE) and QSFP+ (40GbE)
  • Stacking support for up to 12 units
  • Resilient design with hot-swappable power supplies and fans
  • Advanced Layer 3 routing to optimize enterprise traffic
  • Centralized administration via CLI, Web, SNMP, SmartZone, ZoneDirector, or Cloud
  • Engineered for high-performance, low-latency connectivity

Specifications :

SpecificationDetails
Model Number ICX7450-48-E
Product Type managed switch
Port Configuration 48 x 1GbE RJ-45 non-PoE
Expansion Slots 3 x modular (10GbE SFP+ / 40GbE SFP+)
Switching Capacity Up to 176 Gbps
Forwarding Rate Up to 132 Mpps
Stacking Support Up to 12 switches
Redundancy Hot-swappable power supplies & fan trays
Form Factor Rack-Mountable (1U)
Dimensions 17.3 x 16.4 x 1.7 in (440 x 417 x 44 mm)
Weight 16.8 lbs (7.6 kg)
Management CLI, Web GUI, SNMP, SmartZone, ZoneDirector, Cloud
