Detailed Specifications
RUCKUS ICX7550-24P – Enterprise Access PoE Switch
Overview :
The RUCKUS ICX7550-24P is a fixed-configuration, 24-port 1 GbE RJ-45 switch designed for enterprise access deployments requiring Power-over-Ethernet (PoE) support and high uplink/stacking bandwidth. It offers 24 × 10/100/1000 Mbps PoE/PoE+ ports suitable for powering edge devices such as Wi-Fi 6 access points, IP cameras and VoIP phones while providing dual 40 Gbps QSFP+ modules for uplink or stacking to aggregation or core layers. The unit is stackable up to 12 switches, enabling simplified management and distributed access layer design. Its architecture suits campus wiring closets, branch offices or edge aggregation where a unified wired-wireless infrastructure is managed by RUCKUS SmartZone or RUCKUS Cloud platforms. With a non-blocking switching capacity of 368 Gb/s and a maximum PoE budget of 2000 W, it supports demanding PoE deployments without sacrificing network throughput.
Key Features :
24 × 10/100/1000 Mbps RJ-45 ports with PoE/PoE+
2 × 40 Gbps QSFP+ uplink/stacking ports
Stackable up to 12 units for scalable access layers
Non-blocking switching capacity of 368 Gb/s
Supports L2/L3 routing, MACsec and reversible airflow
Specifications
| Specification | Details |
|---|
| Brand | RUCKUS |
| Part Number | ICX7550-24P |
| Product Type | Mid-Range Access 24-Port PoE Switch |
| Switching Capacity | 368 Gb/s |
| RJ-45 Ports | 24 × 10/100/1000 Mbps |
| SFP Ports | 4 × 1 GbE SFP |
| SFP+ Ports | 4 × 10 Gbps SFP+ |
| QSFP/Stacking Ports | 4 × 40 Gbps QSFP |
| Max PoE Power Budget | 2000 W |
| Maximum Switches per Stack | 12 |
| Aggregate Stack Bandwidth | 960 Gb/s |
| Dimensions (H×W×D) | 1.7″ × 17.3″ × 16.0″ (43 × 440 × 406 mm) |
| Weight | 14.86 lbs (6.74 kg) |
| PoE Standard | IEEE 802.3at compatible |
| Routing & Security | L3 STATIC/RIP/OSPF, MACsec support |
