Detailed Specifications
RUCKUS ICX7150-48PF-4X1G – 48-Port Gigabit PoE+ Access Switch
Overview :
The RUCKUS ICX7150-48PF-4X1G is a 48-port 10/100/1000 Mbps RJ-45 switch with full PoE+ support and four 1 Gb SFP uplink/stacking ports, designed for enterprise edge deployments that require both high port density and power-over-Ethernet delivery. It supports a maximum PoE budget of 740 W, allowing deployment of IP cameras, access points and VoIP phones without separate power adapters. The switch supports stacking of up to 12 units with an aggregated stack bandwidth up to 480 Gb/s, enabling simplified management of distributed access switches as a single logical device. It fits in wiring closets, branch offices or campus access layers and integrates with RUCKUS wired-wireless fabric management platforms to deliver unified wired and wireless operations in one domain.
Key Features :
48 × 10/100/1000 Mbps RJ-45 ports with PoE+ support
Four SFP uplink/stacking ports (1 Gb) upgradeable to 10 Gb
740 W maximum PoE budget for powered edge devices
Stack-up to 12 switches for simplified management and scalability
Basic Layer 3 support (static routing, RIP) for access-layer deployments
Specifications
| Specification | Detail |
|---|
| Brand | RUCKUS |
| Part Number | ICX7150-48PF-4X1G |
| Product Type | 48-Port Gigabit PoE+ Stackable Access Switch |
| RJ-45 Ports | 48 × 10/100/1000 Mbps |
| Uplink Ports | 2 × 1 Gb RJ-45 + 4 × 1 Gb SFP (upgradeable) |
| PoE Power Budget | 740 W |
| Switching Capacity | 180 Gb/s |
| Stack Bandwidth | Up to 480 Gb/s |
| Ports per Stack | Up to 12 switches |
| Layer 3 Features | Static routing, RIP |
| Dimensions (H×W×D) | 1.7″ × 17.3″ × 16.1″ (≈ 43.65 × 440 × 409 mm) |
| Weight | 13.9 lbs (≈ 6.3 kg) |
| Fan / Redundant PSU | Single internal PSU, no hot-swap fans |
| Energy Efficient Ethernet | Yes |
