Ruckus ICX8200-48PF – 48-Port Gigabit PoE+ Switch with 25GbE Uplinks
Overview :
The Ruckus ICX8200-48PF is a managed edge switch designed for campus and enterprise environments requiring high-density Power over Ethernet (PoE+) connectivity. It features 48 Gigabit Ethernet ports that support PoE+ (802.3at), delivering up to 740W of power to connected devices such as IP phones, access points, and surveillance cameras. The switch also includes four 25GbE SFP28 ports for high-speed uplinks or stacking, facilitating flexible network expansion and future-proofing. Built with a compact 1U form factor, it is optimized for environments with limited space. The ICX8200-48PF is ideal for organizations seeking a scalable, high-performance solution to support IoT and wireless-first deployments. It offers advanced Layer 2 and Layer 3 features, including VXLAN support, and is managed via Ruckus' SmartZone, Cloud, or Unleashed platforms.
Key Features :
48 x 1GbE PoE+ Ports: Supports up to 740W PoE budget.
4 x 25GbE SFP28 Ports: High-speed uplinks or stacking.
Advanced Layer 2/L3 Features: Includes VXLAN support.
Compact 1U Form Factor: Ideal for space-constrained environments.
Flexible Management Options: Compatible with SmartZone, Cloud, or Unleashed.
Specifications :
| Specification | Details |
|---|
| Brand | Ruckus |
| Part Number | ICX8200-48PF |
| Product Type | Managed Edge Switch |
| Ethernet Ports | 48 x 10/100/1000 Mbps RJ-45 PoE+ |
| Uplink Ports | 4 x 1/10/25 GbE SFP28 |
| PoE Standard | IEEE 802.3at (PoE+) |
| PoE Budget | 740W |
| Switching Capacity | 296 Gbps |
| Stacking Capability | Up to 12 switches per stack |
| Stacking Bandwidth | 1.2 Tbps |
| Management Ports | 1 x USB, 1 x Mini USB |
| Console Ports | 1 x RJ-45, 1 x USB Type-C |
| Airflow Direction | Front-to-back |
| Power Supply | Internal AC, 100–240 VAC, 50–60 Hz |
| Form Factor | 1U Rackmount |
| Dimensions (H x W x D) | 1.75 x 17.3 x 15.5 inches |
| Weight | 12.1 lbs |
