Detailed Specifications
APC SMT750RMI2U Smart UPS Line Interactive 750VA Rackmount 2U 230V
Overview
The APC SMT750RMI2U is a 2U, rack-mountable, line-interactive UPS rated at 750 VA / 500 W, built to protect servers, networking gear, storage, and edge infrastructure in data closets or small racks. It features automatic voltage regulation (AVR) to correct under-/overvoltage without switching to battery, reducing wear on the battery. Under full load, the output distortion stays under 5%. Typical transfer times are ~2 ms. The unit supports input voltages from 160 V to 286 V (adjustable 151 V-302 V for mains operation). It includes 4 IEC C13 outlets + 2 IEC jumper ports for flexible power routing. The internal battery is sealed lead-acid, with a ~3-hour recharge time, and the module supports hot-swap replacement (RBC123). The UPS offers a multi-function LCD console for monitoring and configuration. It is well suited for rack environments where reliable but compact UPS protection is needed for moderate loads like switches, access servers, or voice systems.
Key Features
750 VA / 500 W output capacity with clean sine-wave output
Line-interactive topology with AVR keeps output stable without frequent battery use
Rack 2U form factor fits standard 19″ racks with limited space
4 IEC C13 outlets + 2 jumper ports enable flexible cabling and load distribution
Specifications
| Specification | Detail |
|---|
| Brand | APC by Schneider Electric |
| Part Number | SMT750RMI2U |
| Product Type | Rackmount Line-Interactive UPS |
| Output Power Capacity | 750 VA / 500 W |
| Topology | Line-interactive with AVR |
| Output Connections | 4 × IEC 320 C13 + 2 × IEC jumpering |
| Input Voltage Range | 160-286 V (adjustable 151-302 V) |
| Transfer Time | ~2 ms typical |
| Battery Type / Recharge | Sealed lead-acid, ~3 hour recharge |
| Dimensions (HxWxD) | 86 mm × 432 mm × 409 mm |
| Net Weight | 17.27 kg |
| Warranty | 3 years (excluding battery) |
