Detailed Specifications
APC SMT2200RM2UNC - 2200 VA Rack UPS 1920 W
Overview :
The APC Smart-UPS SMT2200RM2UNC is a 2U rack-mount uninterruptible power supply (UPS) designed for systems engineers and data center technicians who need to maintain uptime for critical IT equipment. It provides controlled shutdown and power protection for servers, network devices, and storage arrays.
This UPS uses a line-interactive topology with automatic voltage regulation (AVR), delivering 1920 VA / 1920 W output with pure sine wave AC. It includes eight battery-backed outlets (2× NEMA 5-20R, 6× NEMA 5-15R) and a built-in network management card for remote monitoring and event alerts.
The 2U form factor fits standard 19″ cabinets, suitable for IDF/MDF racks, branch offices, edge closets, and small data center racks. The unit has a NEMA 5-20P input plug, front LCD console for status monitoring, and transfer times of 4-8 ms during mains power loss.
A practical deployment is protecting a rack of servers and network switches in a branch office with occasional outages. The network management card enables automatic shutdown of hypervisors or databases. It is not suitable for environments requiring extended runtime without external battery packs or for 208/230 V systems without proper variants.
Key Features :
1920 VA / 1920 W line-interactive UPS capacity
8 battery-backed NEMA outlets with mixed receptacles
Integrated network management card pre-installed
AVR to correct brownouts/surges, pure sine wave output
Front LCD status console with real-time metrics
Specifications :
| Specification | Value |
|---|
| Brand | APC |
| Part Number | SMT2200RM2UNC |
| Product Type | Line-Interactive UPS |
| Capacity (VA/W) | 1920 VA / 1920 W |
| Nominal Voltage | 120 V AC |
| Input Range | 75-154 V (adjustable) |
| Frequency | 50/60 Hz ±3 Hz auto-sensing |
| Topology | Line-Interactive |
| Waveform | Pure sine wave |
| Outlets | 2× NEMA 5-20R; 6× NEMA 5-15R |
| Input Connector | NEMA 5-20P, 8 ft cord |
| Transfer Time | 4-8 ms |
| Battery Type | Sealed lead-acid, user-replaceable |
| Runtime (Full Load) | ~5 min |
| Recharge Time | ~3 h |
| Dimensions (W×H×D) | 18.9″ × 3.4″ × 26.9″ |
| Weight | ~93 lb |
