Detailed Specifications
APC SMT2200R2X167 Line-Interactive Rackmount UPS
Overview :
The APC SMT2200R2X167 is a 2200 VA/1980 W line-interactive rackmount UPS designed for IT engineers supporting servers, storage arrays or networking gear during power disturbances. It delivers pure sine wave output and supports automatic voltage regulation (AVR) to correct fluctuations in utility input. The device is built for 2U rack-mount deployment in data centre, edge, or branch environments. It includes ten NEMA 5-15R output receptacles, SmartSlot expansion and auto-sense input voltage of 120 V/230 V, enabling global compatibility. The unit supports USB and serial communication for graceful shutdown and integrates with APC's management tools for monitoring and event logging.
Key Features :
2200 VA / 1980 W capacity in 2U rack chassis
Pure sine-wave output with less than 5% harmonic distortion
Ten NEMA 5-15R outlets for server and network equipment
Auto-sense input voltage 120 V/230 V for flexible installations
Built-in LCD status display and SmartSlot for optional network card
Technical Specifications :
| Specification | Value |
|---|
| Brand | APC |
| Part Number | SMT2200R2X167 |
| Product Type | Line-Interactive Rackmount UPS |
| Rated Power (VA) | 2200 VA |
| Rated Power (Watts) | 1980 W |
| Input Voltage | 120 V |
| Input Voltage Range | 100…290 V (120…230 V auto-sense) |
| Output Voltage | 120 V |
| Output Connections | 10 × NEMA 5-15R |
| Transfer Time | 6 ms typical / 10 ms maximum |
| Dimensions (H×W×D) | 3.39 in × 17.01 in × 26.89 in |
| Net Weight | 93.5 lbs |
| Operating Temperature | 32…104 °F (0…40 °C) |
| Acoustic Noise Level | 55 dBA |
| Surge Energy Rating | 1366 J |
