APC SMTL2200RM2UC 2200VA 2U Lithium-ion Rack UPS
Overview
The APC SMTL2200RM2UC is a line-interactive rackmount uninterruptible power supply (UPS) from APC by Schneider Electric designed to provide regulated AC power and limited backup runtime to critical IT infrastructure. It targets IT engineers, network administrators, and data center operators requiring reliable outage tolerance and voltage conditioning for server, networking, and storage equipment.
The UPS supports up to 2200 VA / 1920 W output using lithium-ion battery chemistry, offering a pure sine wave output compatible with sensitive loads and active PFC power supplies. Its line-interactive topology with Automatic Voltage Regulation (AVR) corrects brownouts and overvoltages without drawing battery reserves under moderate voltage fluctuations.
Mechanically, it occupies 2U of rack space and integrates eight AC outlets (two NEMA 5-20R and six NEMA 5-15R), suitable for mixed current loads and rack-mounted gear. Rack mounting brackets and support rails are included for standardized installation in 19-inch cabinets.
Management interfaces include a SmartConnect Ethernet port, USB, serial, and a SmartSlot for optional network management cards, enabling remote monitoring, firmware updates, and integration with centralized tools such as EcoStruxure IT or third-party platforms.
In real deployments, this UPS is appropriate for edge compute cabinets, IDF/MDF closets, and small data centers where compact footprint and remote monitoring are critical. However, it is not suited for large data halls requiring extended runtime or dualconversion online topology for extremely unstable power environments.
Key Features
• 2U rackmount UPS with eight AC outlets for mixed load types
• 2200 VA / 1920 W lithium-ion power capacity
• Line-interactive topology with AVR
• SmartConnect cloud monitoring and SmartSlot expansion
• Pure sine wave output for active PFC equipment
Specifications
| Specification | Details |
|---|
| Brand | APC by Schneider Electric |
| Part Number | SMTL2200RM2UC |
| Product Type | Line-interactive UPS |
| Output Capacity | 2200 VA / 1920 W |
| Topology | Line-interactive with AVR |
| Nominal Input Voltage | 120 V AC (110-125 V) |
| Nominal Output Voltage | 120 V AC (110-125 V) |
| Frequency | 50/60 Hz auto-sensing |
| Battery Type | Lithium-ion |
| Typical Recharge Time | ~2 hours |
| Outlets | 2× NEMA 5-20R, 6× NEMA 5-15R |
| Input Connection | NEMA 5-20P |
| Waveform | Pure sine wave |
| Rack Height | 2U |
| Dimensions (H×W×D) | 3.39″ × 17.01″ × 26.89″ (86 × 432 × 683 mm) |
| Weight | ~70.3 lb (~31.9 kg) |
| Communication Ports | SmartConnect Ethernet, USB, serial, SmartSlot |
