Detailed Specifications
Vertiv LV5500T-400 Avocent LV5500 High-Performance KVM Extender Transmitter
Overview :
The Vertiv Avocent LongView 5500 Transmitter (LV5500T) is the latest in the Avocent high-performance KVM Extender family of products. The LV5500T comes equipped with a dependable performance along with intelligent EDID management. Coupled with the Avocent LV5500R, the LV5500T is a point-to-point high performance KVM extender that provides 24-bit color graphics over a single head up to 4K @ 60Hz. Increase business security with signed upgrade files and firmware updates from a single USB flash drive. It provides users with real-time access, high resolution clarity, and local console video output. The LV5500T connects either via a copper or fiber link and comes with a LED indicator that shows the quality of the link connection.
Specification :
| Product Name |
Vertiv Avocent LV5500 High-Performance KVM Extender | Transmitter |
| Manufacturer Part Number |
LV5500T-400 |
| Product Type |
KVM Extender Transmitter |
| Maximum Video Resolution |
4096 x 2160 |
| Maximum Operating Distance |
13123.36 ft |
| USB |
Yes |
| HDMI |
No |
| DVI |
No |
| VGA |
No |
| Network (RJ-45) |
Yes |
| DisplayPort |
Yes |
| Product Family |
LongView 5000 |
| Proprietary Interface |
No |
| PS / 2 Port |
No |
| KVM Technology |
Digital |
| Number of Computers Supported |
1 |
| Number of Local Users Supported |
1 |
| Number of Remote Users Supported |
1 |
| TAA Compliant |
Yes |
| Device Type |
High Performance KVM |
| Product Color |
Black |
| Connectivity Technology |
Wired |
| Input Voltage Range |
100-240 VAC |
| Form Factor |
Rack-mountable |
| Environmentally Friendly |
Yes |
| Graphic Mode |
4K |
| Number of HDMI Ports |
0 |
| Headphone |
Yes |
| Number of Network (RJ-45) Ports |
1 |
| Number of USB Ports |
2 |
| Number of PS / 2 Ports |
0 |
| Number of VGA Ports |
0 |
| Number of DVI Ports |
0 |
| Transmitter Height |
1.54" |
| Transmitter Width |
7.32" |
| Transmitter Depth |
5.83" |
| Transmitter Weight (Approximate) |
2.84 lb |
| Country of Origin |
United Kingdom |
| Product Series |
5000 |
| Rack Height |
1U |
| Microphone |
Yes |
| Product Model |
LV5500T |
| Power Consumption |
18 W |
| Product Line |
LongView |
| Input Voltage |
120 V AC 230 V AC |
| Packaged Quantity |
1 |
