Dell R840 5217*2/2*8G DDR4/2*600G SAS 2.5 10k/H330/DVD/4*1GE/2*750W/2.5-8

We can design as per your required specifications, Get in touch with sales@dcsupplies.net

Overview R840

When outfitted with four processors the Dell EMC PowerEdge R840 Server can easily tackle a number of high-performance applications including, data analytics, machine learning, and other data-intensive workloads. It also features Dell’s out-of-band management tools iDRAC and OpenManage for the automation and management of several servers.

Performance R840

You can install two or four Intel Xeon Scalable processors from either the first or second generation. However, you need the CPUs with an “M” suffix if you want to achieve 6TB memory capacity as only those processors with an “M” will support that memory capacity. Gen 2 Intel Xeon Scalable processors support memory speeds of up to 2933MHz, compared to 2666MHz using Gen 1 Scalable processors, they also support more memory in general. There are a number of power options depending on your server configuration.

Memory R840

Each processor supports 12x memory module slots with two modules per channel. There is a total of 48 active memory module slots with a quad-processor configuration. Only DDR4 ECC Registered (RDIMM), Load-Reduced (LRDIMM), or Non-Volatile (NVDIMM) memory modules are supported on this system. Only a total of 384GB of NVDIMM modules are supported, the remaining memory slots can be outfitted with RDIMM memory modules.

Storage R840

There are several storage configurations available on the Dell R840 server including 8x 2.5-inch SAS or SATA, 24x 2.5-inch SAS or SATA with 12 drive bays that can be outfitted with NVMe drives, and a configuration with 24x NVMe drives in front. Two more 2.5-inch SAS or SATA HDDs or SSDs can be installed in a rear drives cage. The system features an S140 integrated software RAID controller but the system is also compatible with Dell’s other controllers including the PERC H330, H730P, H740P, and HBA330. For external storage, you can install a PERC H840 RAID controller. The system also supports Dell’s Boot-optimized Storage Subsystem, AKA BOSS, for support of the OS.

Specifications R840
