Detailed Specifications
TP-LINK TL-SG1005P 5-Port Gigabit Desktop Switch with 4-Port PoE+
Overview :
What This Product Does
TL-SG1005P is a 5 10/100/1000Mbps ports unmanaged switch that requires no configuration and provides 4 PoE (Power over Ethernet) ports. It can automatically detect and supply power with all IEEE 802.3af compliant Powered Devices (PDs). In this situation, the electrical power is transmitted along with data in one single cable allowing you to expand your network to where there are no power lines or outlets, where you wish to fix devices such as APs, IP Cameras or IP Phones, etc.
Power over Ethernet
4 of the 5 Auto-Negotiation RJ45 ports (Port 1 to Port 4) of the switch support Power over Ethernet (PoE) function. These PoE ports can automatically detect and supply power with those IEEE 802.3af-compliant Powered Devices (PDs).
Overload Arrangement
TL-SG1005P has a priority function that will help protect the system when the system power is overloaded. If all PoE PDs power consumption is >= 56W, a priority will be arranged among the PoE ports, then the system will cut off the power of the lowest-priority port.
Features :
- Flexible Full Gigabit 5-Port PoE Configuration: 4x PoE+ (802.3at/af) 10/100/1000 Mbps RJ45 ports providing up to 30W per port and total PoE power budget of 65W, together w/ 1x Gigabit Non-PoE Port for high-speed connections.
- Plug and Play: Easy setup with no software installation or configuration needed.
- Advanced Software Features: Prioritize your traffic and guarantee high quality of video or voice data transmission with Port-based 802.1p/DSCP QoS and IGMP Snooping.
Specifications :
| Product Name |
5-Port Gigabit Desktop Switch with 4-Port PoE+ |
| Product Type |
Ethernet Switch |
| Manageable |
No |
| Ethernet Technology |
Gigabit Ethernet |
| Product Family |
JetStream |
| Stack Port |
No |
| Media Type Supported |
Twisted Pair |
| Total Number of Network Ports |
5 |
| PoE (RJ-45) Port |
Yes |
| Redundant Power Supply Supported |
No |
| Form Factor |
Desktop |
| Power Consumption |
4.30 W |
| Power Source |
Power Adapter |
| Layer Supported |
2 |
| Environmentally Friendly |
Yes |
| Network (RJ-45) |
Yes |
| Modular |
No |
| Uplink Port |
No |
| Port / Expansion Slot Details |
1 x Gigabit Ethernet Network
4 x Gigabit Ethernet PoE+
|
| PoE Budget |
65 W |
| Networking Standards |
IEEE 802.3af
IEEE 802.3at
IEEE 802.3x
IEEE 802.1p
|
| Product Material |
Metal |
| Country of Origin |
China |
| Height |
0" |
| Width |
3.9" |
| Depth |
3.9" |
| Product Model |
TL-SG1005P |
| Network Technology |
10/100/1000Base-T |
| Product Line |
JetStream |
| Limited Warranty |
3 Year |
