HPE Aruba JL320A 2930M 24G PoE+ 1-Slot Switch

New

In Stock

HPE Aruba JL320A 2930M 24-Port Gigabit PoE+ Switch with 1-Slot Module
×




$1,442.00

  • New

Detailed Specifications

HPE JL320A

Aruba JL320A 2930M 24G PoE+ 1‑Slot Managed Ethernet Switch

The JL320A 2930M is a 1U, Layer 3 managed PoE+ access switch with one modular uplink slot. Ideal for enterprise edge, campus, and SMB deployments, it offers powerful performance and integrated wired–wireless security and management capabilities.

Features

Powered by Aruba’s ProVision ASIC, this switch delivers wire-speed forwarding (95.2 Mpps, 128 Gbps) and low latency (<3.1 µs for 1 Gbps)

Advanced Options

Modularity allows you to scale with uplinks (10/40 GbE) and PoE power (up to 1440 W). Supports zero-touch provisioning, stacking, and unified policy enforcement for wired and wireless users.

Product Key Features

  •  24×1 GbE PoE+ ports + 4 combo SFP ports for flexible uplinks

  •  Scalable PoE budget up to 1440 W with dual modular PSUs; each PoE+ port provides up to 30 W (some support 60 W Class 6)

  •  Layer 3 routing (static, RIP, OSPF) and stacking support up to 10 units at 100 Gbps backplane

  •  Unified wired/wireless management via Aruba ClearPass, AirWave, Central, and SDN support (REST, OpenFlow 1.3)

  •  Uplink flexibility: single modular slot supporting 10 GbE SFP+ or 40 GbE QSFP+ modules

  •  Robust QoS & security: ACLs, 802.1X, MACsec, DHCP snooping, sFlow, LLDP‑MED, and more

Reliability & Performance

Equipped with dual redundant power supplies, high PoE power budgets, and advanced stacking, the JL320A ensures high availability and future scalability. Aruba’s management suite and SDN support make it ideal for secure and flexible network designs.

Key Features (Bullet List)

    • 20 × PoE+ RJ-45 + 4 combo RJ-45/SFP ports

    • Single modular uplink slot (10 GbE/40 GbE)

    • 128 Gbps switching fabric; 95.2 Mpps throughput

    • Layer 3 routing: static, RIP, OSPF; IPv4/IPv6 support

    • Stacks up to 10 units (100 Gbps backplane)

    • PoE+ up to 30 W/port; up to 60 W Class 6 in newer models

    • QoS: IEEE 802.1p, ACLs, sFlow

    • Security: 802.1X, MACsec, DHCP snooping, LLDP-MED

    • Management: CLI, GUI, SNMP, Aruba Central/ClearPass/AirWave, REST, OpenFlow

SpecDetails
Model Number JL320A
Type 1RU Layer 3 Managed Switch (PoE+)
Ports 20 × 10/100/1000 PoE+ RJ‑45 + 4 combo RJ‑45/SFP
Uplink Slot 1 × modular (10 GbE SFP+ or 40 GbE QSFP+)
Switching Capacity/Throughput 128 Gbps / 95.2 Mpps
Latency <3.1 µs (1 Gbps), <3.4 µs (10 Gbps)
PoE Budget Up to 1440 W (dual PSUs); 30 W per port, Class 6=60 W
Routing Static, RIP v1/v2/ng, OSPF v2/v3
Stacking Up to 10 units, 100 Gbps backplane
Management CLI, Web GUI, SNMP v1/2/3, Aruba Central/AirWave
SDN Support REST APIs, OpenFlow 1.3
Security Features 802.1X, MACsec, ACLs, DHCP Snooping, LLDP-MED
QoS 802.1p, DiffServ, sFlow
Dimensions (WxDxH) 17.4″ × 12.8″ × 1.73″ (44.2×32.4×4.4 cm)
Weight ~4.5 kg (9.9 lb)
Power Supply Internal PSU + optional modular PSU
Operating Temp/Humidity 0–50 °C / 15–95% non-condensing
