The HPE Aruba Networking 2930M Switch Series is designed for digital workplaces optimized for mobile users. These powerful Layer 3 access switches are easy to deploy and manage with advanced security and network management tools like HPE Aruba Networking ClearPass Policy Manager, HPE Aruba Networking AirWave and cloud-based HPE Aruba Networking Central. Modular stacking, uplinks and power provide scalability and simplicity for enterprise edge, SMB and branch office networks. The HPE Aruba Networking 2930M Switch Serie delivers performance and value with support for static, RIP and Access OSPF routing, 10GbE and 40GbE uplinks, models with 24 ports of HPE Smart Rate multi-gigabit Ethernet, up to 1440W of PoE, robust QoS, and Dynamic Segmentation for unified and secure access.
Specifications :
| Specification | Details |
|---|---|
| Part Number | JL321A |
| Product Type | Ethernet Switch |
| Brand | HPE Aruba |
| Model | 2930M 48G 1-Slot Switch |
| Form Factor | Rack-mountable, 1U |
| Total Ports | 48 x Gigabit Ethernet (10/100/1000) |
| Slot Expansion | 1 x Module Slot |
| Uplink Ports | 4 x SFP+ (10GbE) via optional expansion module |
| Switching Capacity | 176 Gbps |
| Forwarding Rate | 131 Mpps |
| Stacking Capability | Yes, up to 10 switches (requires stacking module) |
| Routing | Static, RIP, OSPF, PIM, and more (Layer 3 capabilities) |
| Power over Ethernet (PoE) | PoE+ Supported (370W via optional power supplies) |
| MAC Address Table | 16K entries |
| VLAN Support | Up to 4094 VLANs |
| Management | Web-based GUI, Command Line Interface (CLI), SNMP |
| QoS | Yes, advanced traffic prioritization |
| Security Features | ACLs, 802.1X, MAC Authentication, RADIUS/TACACS+ |
| Power Supply | 1 modular power supply slot (power supply sold separately) |
| Operating Temperature | 0°C to 45°C (32°F to 113°F) |
| Dimensions | 17.42 x 12.01 x 1.73 inches (442.5 x 305 x 44 mm) |
| Weight | 9.26 lbs (4.2 kg) |
| Warranty | Limited Lifetime Warranty |
| Certifications | RoHS, CE, FCC |
