Fortinet FS-524D FortiSwitch 524D 24-Port Managed Gigabit Ethernet Switch

Fortinet FS-524D

FortiSwitch 524D 24-Port Managed Gigabit Ethernet Switch

The Fortinet FortiSwitch 524D is a 24-port managed Gigabit Ethernet switch built for high-performance enterprise networking. Offering advanced Layer 2/3 management, PoE capabilities, and full integration with the Fortinet Security Fabric, it's ideal for campuses, branch offices, and data centers. This switch delivers secure, scalable, and efficient network connectivity.

Features :

With support for VLANs, Quality of Service (QoS), Link Aggregation Control Protocol (LACP), and ACLs, the FS-524D allows IT administrators to optimize, segment, and secure network traffic. Seamless integration with FortiGate firewalls and FortiManager provides centralized policy enforcement and monitoring, streamlining network operations.

Advanced Options :

Equipped with 24 Gigabit Ethernet ports that support PoE (802.3at/af), the FS-524D powers wireless APs, IP phones, and other PoE-enabled devices without the need for separate power adaptors. Four 10GE SFP+ uplink ports provide high-speed aggregation and backbone connectivity. Energy-efficient technology, robust cooling, and rack-mount design ensure reliability for continuous enterprise operation.

Product Key Features

• 24 Gigabit Ethernet ports with PoE support
• Managed Layer 2/3 switch with VLAN, QoS, and LACP
• Seamless integration with Fortinet Security Fabric
• High-performance switching ideal for enterprise environments
• Energy-efficient operation with robust cooling
• Suitable for campus, branch, and data center deployments

---

Reliability & Performance :

The FS-524D combines enterprise-grade performance with robust hardware design and energy efficiency. PoE support, high switching capacity, and advanced traffic management features ensure optimized performance and reliability. Centralized management via FortiGate or FortiManager simplifies administration, while security features like port security and 802.1X authentication protect devices and data.

Key Features :

• 24 × GE RJ45 ports with PoE (802.3at/af)
• 4 × 10GE SFP+ uplinks for high-speed aggregation
• 128 Gbps switching capacity with 95 Mpps forwarding rate
• Advanced traffic management: VLAN, QoS, LACP
• Fortinet Security Fabric integration
• Energy-efficient and rack-mountable design

Specifications :

Specification	Details
Model Number	FS-524D
Brand	Fortinet
Product Type	Managed Gigabit Ethernet Switch
Ports	24 × GE RJ45, 4 × 10GE SFP+
PoE Support	Yes, 802.3at/af
Switching Capacity	128 Gbps
Forwarding Rate	95 Mpps
VLAN	4K supported
QoS	8 queues per port, ACL-based
LACP	Yes
Power Supply	Internal, 100-240V AC
Max Power Consumption	370W
Dimensions	1.75 × 17.5 × 12 in (1U Rackmount)
Weight	7.5 kg
Management	FortiGate, FortiManager, Web GUI, CLI
Operating Temperature	0°C to 40°C
