HPEJ9836AS

Aruba(2920-48G-PoE+ 740 W) Fully Managed Layer 3 Switch- 48 Ports PoE+

The HPEArubaJ9836A is part of the Aruba2920 Switch Series offering 44 auto-sensing 1 GbE PoE+ ports and 4 dual-personality combo Gigabit ports for copper or SFP mini-GBIC. With an internal 740 W PoE+ budget, it supports high-density deployments of Wi-Fi APs, IP phones, security cameras, and IoT devices without auxiliary injectors. Fully managed with Layer 3 capabilities×static IP routing, RIP-1/2, multicast MLD×it is ideal for SMB, campus access, and branch office networks seeking enterprise-grade performance and simplicity. Stackable via optional module (up to 4 units) for single-IP management, this model combines reliability, scalability, and flexibility in a standard 1U rack format.

Features

Building on the Aruba2920 architecture, the J9836A delivers 176 Gb/s switching capacity and supports packet throughput up to 130.9 Mpps, with low-layer 3 latency (≤ 3.2 µs for 1 Gb/s and 10 Gb/s packets). Powered by a tri-core ARM1176 processor at 625 MHz with 512 MB SDRAM and 1 GB flash, plus 11.25 MB packet buffer, it provides stable performance under sustained throughput and PoE loadsManagement includes CLI, web GUI, ArubaCentral integration, AirWave, SNMPv1/v2c/v3, RMON, Telnet, FTP, and REST API support. Dual personality port design allows flexibility in uplink choice: copper or fiber SFP with PoE function support. Supports IPv4 routing table up to 2,048 entries and IPv6 up to 256 entries as well as MAC table size of ~16,000 entries

Advanced Options

The switch provides enterprise-grade features such as 802.3at PoE+, Auto-MDIX, energy-efficient Ethernet, LACP trunking, LLDP, STP variants, UDLD, ACLs, QoS with CoS support, VLAN segmentation, and jumbo frames up to 9,220 bytes Optional stacking (up to 4 units) simplifies network growth while maintaining unified management. Designed for dependable, high-capacity edge networking, this switch ensures precise forwarding performance thanks to its robust hardware architecture and large buffer memory. The PoE+ budget of 740 W supports high-port-power devices such as high-end APs or PTZ cameras without requiring external injectors . With idle consumption at just ~52 W and maximum power draw under heavy load at 487 W, efficiency is optimized even under full utilization Operating silently (~53 dB acoustic power) and within an operating temperature range of 0-55 °C, the switch is well-suited to enterprise rack and closet environments. Stack resilience ensures redundancy, combined with enterprise-class features like ACL-based segmentation, energy-efficient EEE, and robust QoS prioritization for critical data and voice traffic

Product Key Features

• 44 × 10/100/1000 Mb/s PoE+ copper ports; 4 × combo copper/SFP PoE+ ports

• 740 W PoE+ power budget

• Layer 3 managed switch: static routing, RIP-1/2, MLD support

• Switching capacity: 176 Gb/s; throughput ~130.9 Mpps

• Low latency: ≤ 3.2 µs at line rate

• Stackable up to 4 units via optional module

• Secure management: SSH, SNMPv3, RADIUS/TACACS+, CLI/Web GUI/REST API

---

Reliability & Performance

Warranty-backed firmware and hardware support enable long-term deployment confidence. Management flexibility via ArubaCentral or traditional CLI/web interfaces ensures operational agility across campus or branch deployments. With full PoE+ support, stacking capability, and advanced Layer 3 functions, this switch is ideal for scalable enterprise edge switching needs.

Key Features :

• 48 × autosensing Gigabit ports (44 fixed + 4 combo PoE+ ports)

• 740 W integrated PoE+ power budget

• Layer 3 lite routing: static IP, RIP-1/2, multicast routing

• Up to 130.9 Mpps throughput; 176 Gb/s switching bandwidth

• Low latency (~3.2 µs at 1/10 Gb)

• Stackable (up to 4 units) with single-IP management

• Security: SSHv2, RADIUS/TACACS+, ACLs, QoS, sFlow, Energy Efficient Ethernet

Specification	Details
Model Number	J9836AS (Aruba2920-48G-PoE+ 740 W)
Product Type	48-port Managed Gigabit PoE+ Layer 3 Switch
Ports	44 × Gigabit PoE+ RJ-45; 4 × dual-personality Gigabit RJ-45/SFP
PoE Budget	740 W internal (expandable with EPS)
Stacking Capacity	Up to 4 units; single-IP admin
Switching Capacity	176 Gb/s
Packet Throughput	~130.9 Mpps
Latency	<3.2 µs at 1/10 Gb/s
Routing Table Size	IPv4: 2,048; IPv6: 256
MAC Table Size	~16,000 entries
Buffer Memory	11.25 MB (6.75 MB egress + 4.5 MB ingress)
CPU & Memory	Tri-core ARM1176 625 MHz; 512 MB SDRAM; 1 GB flash
Jumbo Frame	Up to 9,220 bytes
Management Interfaces	CLI, Web GUI, SNMP v1/v2c/v3, RMON, SSH, Telnet, FTP, REST API
Supported Protocols	VLAN, STP variants, LACP, LLDP, UDLD, ACLs, QoS, IPv6, sFlow
Dimensions	44.25 × 33.6 × 4.39 cm (1U)
Weight	~5.83 kg
Temperature Range	0-55 °C; humidity 15-95% non-condensing; altitude up to 3 km
Warranty	ArubaLifetime Hardware Warranty
