Detailed Specifications
RUCKUS ICX7450-24P-E2 – 24-Port PoE+ 1 GbE Access Switch
Overview :
The RUCKUS ICX7450-24P-E2 is a fixed-form-factor, 24-port gigabit Ethernet access switch with full Power over Ethernet plus (PoE+) support, designed for campus edge and high-density wiring closet environments. It provides 24 × 10/100/1000 Mbps RJ-45 ports with PoE/PoE+ and supports high-budget power delivery, making it suitable for connecting IP phones, wireless access-points and surveillance cameras. The switch includes modular uplink/stacking slots supporting 10 GbE and 40 GbE modules, enabling it to scale into aggregation layers or stack up to 12 units for up to 960 Gb/s of stack bandwidth. With robust Layer 3 features (static, RIP, OSPF) and optional advanced functions like MACsec encryption and OpenFlow hybrid mode, it is a fit for enterprise-grade deployments. Its design supports both front-to-back or back-to-front airflow, redundant power solutions and hot-swappable components, aligning with demanding campus infrastructure needs.
Key Features :
Delivers up to 1 500 W PoE budget for edge devices
Modular uplink/stacking slots enabling 10 GbE or 40 GbE modules
Supports stacking of up to 12 switches with 960 Gb/s bandwidth
Full Layer 3 routing support (RIP, OSPF, static) built-in
Supports IEEE 802.3bt/PoH (up to 90 W per port on dedicated ports)
Specifications
| Specification | Value |
|---|
| Brand | RUCKUS |
| Part Number | ICX7450-24P-E2 |
| Product Type | 24-Port 1 GbE PoE+ Access Switch |
| Switching Capacity (max) | 288 Gb/s |
| 1 GbE RJ-45 Ports (max) | 24 |
| 1 GbE SFP Ports (max) | 4 |
| 10 GbE SFP+ Ports (max) | 12 |
| 40 GbE QSFP Ports (max) | 3 |
| PoE Power Budget (max) | 1500 W |
| Stacks per Unit (max) | 12 |
| Aggregate Stack Bandwidth | 960 Gb/s |
| Weight | 15.21 lbs |
| Dimensions (H×W×D) | 1.72 in × 17.32 in × 15.50 in |
| PoE Standard Support | PoE, PoE+, ready for 802.3bt/PoH up to 90 W |
| Layer 3 Features | Static, RIP, OSPF routing |
