StarTech DK30C2DPEP Hybrid Universal Laptop Docking Station with 100W Power Deliver
Overview:
The transition DK30C2DPEP from the legacy USB-A (USB 3.0) to the new USB-C with this certified universal laptop docking station for USB-C and USB-A laptops. The USB-C dock features 100W Power Delivery 3.0, dual HDMI and/or DisplayPort monitors, fast-charge, and both USB-C and USB-A peripheral ports.
The Uniquely Universal Host Cable
The USB-C thunderbolt dock comes with a universal host cable that is designed with an attached USB-C to USB-A adapter to accommodate USB-A laptops. The cable also features an extended length of 1 meter (3.3 ft.) to support a wide variety of workstation setups.
Replacement or extra cables can be purchased separately here.
100W Power Delivery
For high-performance laptops that require more charging power, the dock powers and charges your docking station for laptop as you work with 100W PD for faster charging, using the 150W power adapter - all through a single cable.
Flexible Monitor Connections
This is a dual 4K60Hz video docking station with support for both Ultra HD DisplayPort and/or HDMI monitors that lets you configure your video connections to best suit your needs.
Dual 4K DisplayPort | Up to 4096 x 2160p @ 60Hz
Dual 4K HDMI | Up to 4096 x 2160p @ 60Hz
Single 4K DisplayPort + Single 4K HDMI | Up to 4096 x 2160p @ 60Hz
Single 5K DisplayPort * | Up to 5120 × 2880
*Requires monitor support for 5K using two DP ports
Certified for Universal Compatibility & Reliability
This docking station is fully certified to meet top industry standards for USB-IF (USB 3.1 Gen 1, USB Type-C and Power Delivery), VESA DisplayPort and DisplayLink (video connections) certification to guarantee the highest quality, reliability, and compatibility.
Easy and Convenient Setup
For fast setup right out of the box, the combo cable (USB-C with attached USB-A adapter) lets you connect any laptop. The dock has mounting holes for workstation mounting (bracket not included).
Specifications:
| Product Name |
USB-C & USB-A Hybrid Dock with 100W PD - Dual 4K 60Hz HDMI / DP |
| Manufacturer Part Number |
DK30C2DPEP |
| Product Type |
Docking Station |
| Ethernet Technology |
Gigabit Ethernet |
| HDMI |
Yes |
| Network (RJ-45) |
Yes |
| Maximum Power Supply Wattage |
100 W |
| DisplayPort |
Yes |
| Total Number of USB Ports |
4 |
| Number of USB 3.0 Ports |
4 |
| USB Type-C |
Yes |
| Connectivity Technology |
Wired |
| Device Supported |
Notebook |
| Host Interface |
USB Type C |
| Environmentally Friendly |
Yes |
| Audio Line Out |
Yes |
| Number of DisplayPort Outputs |
2 |
| Number of HDMI Outputs |
2 |
| Number of Displays Supported |
2 |
| Kensington Security Slot |
Yes |
| Number of USB Type-C Ports |
1 |
| Number of USB Type-A Ports |
3 |
| Supported Resolutions |
4096 x 2160
5120 x 2880
|
| USB Type-A |
Yes |
| Screen Mode Supported |
5K |
| Country of Origin |
China |
| Height |
1.20" |
| Width |
3.10" |
| Depth |
8.70" |
| Packaged Quantity |
1 |
| Brand Compatibility |
Apple
Dell
HP
Lenovo
|
