Detailed Specifications
VisionTek 901499 Docking Station
Overview :
The VisionTek VT7100 Triple Display 4K Docking Station with 100W Power Delivery allows you to easily connect your Windows', Mac' or Chrome' laptop up to three 4K displays and up to 8 accessories and peripherals through a single USB connection. Supports 2 Displays (HDMI or DP) via DisplayLink, Supports 1 Display (HDMI) via DP Alt Mode, USB-C connection to host system, 1 x HDMI (DisplayLink), 1 x DP (DisplayLink), 1 x HDMI (DP Alt Mode), 4 x USB-A (5Gbps), 1 x USB-C (5Gbps), 1 x USB-A Quick Charge, 1 x USB-C Power Delivery, Audio/Mic, Ethernet, Kensington Lock, 100W of Power Delivery via USB-C, USB-A does not provide power.
- Universal Compatibility for USB Type-C
- Supports up to 3 external displays
- 4 x USB-A 3.1 Gen1 Ports 5Gbps
- 1 x USB-A Quick Charge Port
- 1 x DisplayPort 1.2
Specifications :
| Product Name | VT7100 3X 4K Dock W 100W |
| Manufacturer Part Number | 901499 |
| Product Type | Docking Station |
| Ethernet Technology | Gigabit Ethernet |
| HDMI | Yes |
| VGA | Yes |
| Network (RJ-45) | Yes |
| Maximum Power Supply Wattage | 100 W |
| DisplayPort | Yes |
| USB Type-C | Yes |
| Product Color | Silver |
| Connectivity Technology | Wired |
| Host Interface | USB Type C |
| HDMI Version | 2.0 |
| Number of HDMI Ports | 2 |
| Number of Displays Supported | 3 |
| Number of DisplayPorts | 1 |
| Headphone / Microphone Combo Port | Yes |
| Number of RJ-45 Ports | 1 |
| Kensington Security Slot | Yes |
| USB Type-C Detail | 1 x USB-C Power Delivery Port (No Data) |
| DisplayPort Version | 1.2 |
| Number of USB Type-C Ports | 1 |
| Number of USB Type-A Ports | 1 |
| Number of USB 3.1 Gen 1 Type-C Ports | 1 |
| Number of USB 3.1 Gen 1 Type-A Ports | 4 |
| Supported Resolutions | 4096 x 2160, 3840 x 2160 |
| USB Type-A | Yes |
| Screen Mode Supported | 4K |
| Country of Origin | Vietnam |
| Operating System Supported | Windows, ChromeOS, macOS |
| Product Model | VT7100 |
